Used ARBURG 520 A 1600-400 Electric machines
ARBURG 520 A 1600-400 All Electric
13
Données sur les annonces
Numéro de référence
18591
Nom de la machine
Used ARBURG 520 A 1600-400 Electric machines
Fabricant
ARBURG
Type
520 A 1600-400 All Electric
Année
2005
Condition
occassion
Emplacement de l`annonce
Schmiedestraße 3, 45527 Hattingen, Germany
Description
Ref. no.: 18591
Hersteller: ARBURG
Year of construction: 2005
Clamping unit
Clamping force: 160 ton
Opening stroke: 450 mm
Distance between tie bars: 520 x 520 mm
Mould height min.: 250 mm
Mould height max.: 550 mm
Opening width: 700 mm
Platen size (h x v): 695 x 695 mm
Injection unit
Screw diameter: 45 mm
Injection volume: 254 cm³
Shot weight: 232 g
Injection pressure: 1580 bar
Measurements and weight
Machine weight: 7100 kg
Dimensions LxWxH part 1: 5,1 x 1,7 x 2,3 m
Further information:
The ARBURG 520 A series is part of the fully electric ALLROUNDER range and is known for its high precision, energy efficiency, and reliability in injection molding processes.
These machines are particularly suitable for the production of technical plastic parts with high quality requirements, as well as for applications where repeatability and process stability are essential.
Typical features of this series include:
* Fully electric drive for all main movements
* High energy efficiency compared to hydraulic machines
* Excellent injection and positioning accuracy
* Quiet and clean operation (also suitable for medical applications)
* Low maintenance requirements
The 520 A series with 160 tons clamping force offers a very good balance between performance and flexibility and is widely used in industries such as automotive supply, medical technology, and technical plastics.
ARBURG machines are well known for their durability and long service life, which makes this series highly attractive on the used machinery market.
L`annonce a été traduite automatiquement et certaines erreurs de traduction peuvent s`être produites.
