Stok A134R-R5PS6M / 1650 x 2050P Laminasyon Makinası

Teşhir ve ambalaj malzemesi üretimi için levhadan kartona laminasyon makinesi

İlan otomatik olarak çevrildiği için bazı hatalar oluşmuş olabilir.

Sallmetal Laminasyon makinesi

S1050

Maksimum Laminasyon Boyutu: 105 cm


İlan otomatik olarak çevrildiği için bazı hatalar oluşmuş olabilir.

Stock LM 123


A simple semi-automatic spot labeling machine suitable for running (labeling) substrate sheets, flat boxes, blanks, as well as pre-folded (RSC´s) with litho printed labels. Equipped with an automatic label feeder and take-off table. The label is mounted to the lower side of the substrate sheet.

Label Feeder (4E): Suction feeder, for automatically feeding of the labels. The labels have to be pre-loaded on the pile board by hand. Pre-loading height: approx. 7.8”. On sheet removal the pile is re-timing automatically. A suction bar is separating the labels at their front edge, always sucking a single sheet and transporting it into the machine.

Label Registering Unit (LM-1) includes a timed suction conveyor that incorporates a separate motor drive that takes the glued labels after leaving the gluing unit and automatically registers the labels. Precise registration is achieved utilizing the unit’s adjustable side and rear edge guides that are set to the dimensions required for the proper registration of the corrugated sheet or box.

A 2-cylinder gluing unit is utilized for glue application and metering roller with stripping needles. The glue is applied to the label that is then stripped off the application roller by special stripping needles. The litho printed label will always be glued. The Model LM includes an automatic glue-feeding system with diaphragm pump (P).

Squeeze roller that presses the labelled sheets and blanks together.
Integrated sensor for detecting and registering the glued label
Label registering unit for placing and applying the corrugated blank to the glued label
Manual feeding of the corrugated blank or box pressure roller
Take-off table for the manual take-off of the labeled sheets / blanks.
Integrated sheet counter.
Siemens PLC control.
Suction belt

İlan otomatik olarak çevrildiği için bazı hatalar oluşmuş olabilir.

Paperplast uluslararası Kuru 40

Biçim: 76x102

Şunlardan oluşur:
Yaprak besleyici
kalender
Ayırıcı İstifleyici
çevrimdışı ısıtıcı
