Hydraulic CNC press brake HESSE by DURMA AD-Servo 30320
HESSE by DURMA AD-Servo 30320
4
Advert data
Reference number
#A-140
Machine designation
Hydraulic CNC press brake HESSE by DURMA AD-Servo 30320
Manufacturer
HESSE by DURMA
Type
AD-Servo 30320
Condition
new
Location of the advert
Industriezentrum Nö-süd Straße 4 - Objekt 8, 2351 Wiener neudorf, Austria
Description
pressing capacity: 320 to
Bending length: 3050 mm
Axes: Y1 / Y2 / X and R axis
Stroke: 365 mm
Inside distance between side frames: 2600 mm
Gap in side frame: 410 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 160 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 160
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 104 mm
Motor power: 2 x 11 kW
Length: 4300 mm
Width: 1820 mm
Height: 3330 mm
Weight: 16500 kg
