Laser power: 6 kW
Manual table / shuttle table: Manual table
Max. thickness - mild steel: 20 mm
Max. thickness - stainless steel: 15 mm
Max. thickness - aluminium: 20 mm
Max. Application Range - Copper: 10 mm
Max. Application Range - Brass: 12 mm
Cutting area: 3.048 x 1.530 mm
X-axis: 3048 mm
Y-axis: 1530 mm
Z-Axis: 125 mm
Max. Sheet size: 3.048 x 1.524 mm
Max. sheet weight: 127 kg/m²
Max speed x-axes: 90 m/min
Max speed y-axes: 90 m/min
Max. speed simultaneous: 127 m/min
Max. acceleration: 14 m/s²
Positioning accuracy: +/- 0,05 mm
Repeat accuracy: +/- 0,05 mm
Weight: 6600 kg

Laser power: 6 kW
Manual table / shuttle table: Shuttle table
Max. thickness - mild steel: 20 mm
Max. thickness - stainless steel: 15 mm
Max. thickness - aluminium: 20 mm
Max. Application Range - Copper: 10 mm
Max. Application Range - Brass: 12 mm
Cutting area: 3.048 x 1.530 mm
X-axis: 3060 mm
Y-axis: 1530 mm
Z-Axis: 140 mm
Max. Sheet size: 3.048 x 1.524 mm
Max speed x-axes: 90 m/min
Max speed y-axes: 90 m/min
Max. speed simultaneous: 127 m/min
Max. acceleration: 14 m/s²
Positioning accuracy: +/- 0,05 mm
Repeat accuracy: +/- 0,05 mm

Bending length: 1250 mm
Sheet thickness (420 N/mm²): 1.25 mm
Max. thickness - stainless steel: 0.8 mm
Max. thickness - aluminium: 2 mm
Max. bending angle: 150 °
Back gauge manual: 500 mm
Max. opening width without tools: 200 mm
Upper tool: geteilt, 45°
Bending flange: adjustment 35 mm
Length: 1500 mm
Width: 750 mm
Height: 1715 mm
Weight: 315 kg

Coil weight: 500 kg
Coil outer diameter: 1200 mm
Min. coil inner diameter: 470 mm
Max. Coil inner diameter: 520
Max. coil width: 300 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm
Motor: 0.55 kW
Length: 1400 mm
Width: 1200 mm
Height: 1550 mm
Weight: 190 kg

Späneförderer / Schwarz / Neu



Technische Daten:



Gesamtlänge: 4150mm

Gesamthöhe: 1770mm

Auswurfhöhe : 1200mm

Einschublänge: 2950mm

Einschubbreite: 380mm

Einschubhöhe: 340mm

Gewicht: 230 Kg

WEILER LZ 330 aus Bildungseinrichtung

-Drehdurchmesser über Bett 330
-Drehdurchmesser über Support 165mm
-Drehlänge 800mm
-Drehzahlbereich / Stufenlos 25-2800 1/min
-Automatische Längs / Planvorschübe
-Antriebsleistung ca. 3Kw

-Multifix mit Einsätzen
- 2x Dreibackenfutter
- 1x Vierbackenfutter
- 1x Planscheibe
- Spannzangeneinrichtung mit Spannzangen
- Diverses Zubehör
- Dokumentation

Abmaße:
LxBxH 1,8x0,7x1,6 Meter / Gewicht 750Kg


Irrtümer / Eingabefehler vorbehalten
Bsc929Gqgbi

MIKRON A21/2 Zahnrad-Abwälzfräsmaschine

-Komplette technische Daten siehe Fotos
-Wechselräder
-Mitutoyo Lupe
-Originale Betriebsanleitung komplett
-viele Ersatzteile
-Sehr gepflegter Allgemeinzustand


Abmessungen
LxBxH 1,2x1x1,6 Meter / Gewicht 1000Kg

Cef33W8Vwa

ALPA RVC - 250 Rundtischflachschleifmaschine<br /><br />-Magnetdurchmesser 300mm<br />-Magnetdrehtisch / zweistufig<br />-Höhenverstellung per Hand<br />-Schleifhöhe ca. 130mm<br />-Seitliche Schleifscheibenabzieheinichtung<br />-Kühlmitteleinrichtung<br />-Maschinenumhausung<br />-Maschinenfüße<br />Cnj7Zheuvu<br />-Umbau der Elektrik - Neu<br />-Zwei Ersatzschleifscheiben<br />-Bedienwerkzeug<br /><br /><br />Abmaße:<br />LxBxH 1,2x1x1,8 Meter /Gewicht 850Kg

Werkzeugfräsmaschine MAHO MH 800

-Verfahrwege X/Y/Z 700-350-450mm
-Tischfläche 940x510mm
-Spindelaufnahme SK 40
-Spindeldrehzahlen 32-1600 U/min
-Automatische Längs / Quervorschübe
-Automatischer Vorschub / Vertikalfräskopf
-Kühlmitteleinrichtung
Cpm3Ylytuw
-Diverse Werkzeugaufnahmen
-Weitere technische Daten / Siehe Fotos

Abmaße:
LxBxH 1.9x1,7x1,9 Meter / Gewicht: 3500Kg

Punching power: 110 ton
Throat depth: 300 mm
Number of stations: 5
Cylinder: 2
Max. diameter at sheet thickness (mild steel): 40x20 (28x28) mm
Stroke: 80 mm
Strokes: 17 1/min
Flat steel: 600x15 (400x20) mm
Blade length: 605 mm
Angle steel: 152x152x13 mm
Round / square steel: 50/50 mm
Notcher: 90x52x13 mm
Motor: 5 kW
Length: 2130 mm
Width: 1200 mm
Height: 2200 mm
Weight: 2500 kg

Saw frame: Pivot frame
Band dimensions: 5200x34x1,1 mm
Band speed continous: 20-100 m/min
Cutting capacity 0° round: 440 mm
Cutting capacity 0° square: 440 mm
Cutting capacity 0° flat: 610x440 mm
Cutting capacity 45°: rund 410 mm, quadrat 410 mm, rechteck 410 x 440 mm
Cutting capacity 60°: rund 320 mm, quadrat 250 mm, rechteck 250 x 440 mm
Cutting capacity - 45°: rund 410 mm, quadrat 410 mm, rechteck 410 x 440 mm
Cutting capacity - 60°: rund 320 mm, quadrat 285 mm, rechteck 285 x 440 mm
Working height: 860 mm
Hydraulic motor: 0.55 kW
Motor: 3 kW
Coolant pump motor: 0.12 kW
Length: 2800 mm
Width: 1210 mm
Height: 1870 mm
Weight: 1540 kg

Punching power: 50 ton
Throat depth: 177 mm
Number of stations: 5
Cylinder: 1
Max. diameter at sheet thickness (mild steel): 31 x 12 mm
Strokes: 34 1/min
Flat steel: 350 x 15 mm
Angle steel: 80 x 8 mm
Round / square steel: 35 / 30 mm
Notcher: 10 mm
Bending unit: 100 x 10 mm
Motor: 3 kW
Length: 1300 mm
Width: 1100 mm
Height: 1850 mm
Weight: 950 kg

Sheet Thickness - mild steel: 0.6 - 4 mm
Max. sheet width: 300 mm
Max. cross-section: 900 mm
Feed roll diameter: 80 mm
Motor torque: 10 Nm
Motor: 2.62 kW
Length: 1000 mm
Width: 800 mm
Height: 1400 mm
Weight: 330 kg

Working width: 650
Sheet thickness range - mild steel: 0,5 - 170 mm
Grinding belt dimensions: 670 x 2200 mm
Suction capacity: 4000 m³/h
Connection for dust collector diam.: 120 mm
Air connection: 6 bar
Noise level: 83 dB
Motor: 22 kW
Length: 2600 mm
Width: 1350 mm
Height: 2100 mm
Weight: 1125 kg

Punching power: 80 ton
Throat depth: 510 mm
Max. diameter at sheet thickness (mild steel): 40x14 mm
Max. number of strokes at 20 mm stroke: 40 1/min
Motor: 9 kW
Length: 1700 mm
Width: 1300 mm
Height: 2050 mm
Weight: 1715 kg

Punching power: 55 ton
Throat depth: 750 mm
Max. diameter at sheet thickness (mild steel): 40x14 mm
Max. number of strokes at 20 mm stroke: 37 1/min
Motor: 5 kW
Length: 1930 mm
Width: 1200 mm
Height: 1800 mm
Weight: 1885 kg

Coil weight: 4000 kg
Coil outer diameter: 1300 mm
Min. coil inner diameter: 450 - 550 mm
Max. coil width: 600 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm

Coil weight: 2500 kg
Coil outer diameter: 1300 mm
Min. coil inner diameter: 450 mm
Max. Coil inner diameter: 550
Max. coil width: 600 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm

Coil weight: 2500 kg
Coil outer diameter: 1300 mm
Min. coil inner diameter: 450 - 550 mm
Max. coil width: 400 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm

Coil weight: 1250 kg
Coil outer diameter: 1300 mm
Min. coil inner diameter: 450 - 550 mm
Max. coil width: 400 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm

Sheet Thickness - mild steel: 0.4 - 2 mm
Max. sheet width: 600 mm
Max. cross-section: 600x2 mm
Feed roll diameter: 80 mm
Motor torque: 10 Nm

Sheet Thickness - mild steel: 0.4 - 3 mm
Max. sheet width: 400 mm
Max. cross-section: 400x3 mm
Feed roll diameter: 80 mm
Motor torque: 10 Nm

Sheet Thickness - mild steel: 0.4 - 3 mm
Max. sheet width: 300 mm
Max. cross-section: 300x3 mm
Feed roll diameter: 80 mm
Motor torque: 10 Nm

Bending length: 350 - 2800 mm
Max. sheet length: 3050 mm
Max. sheet width: 1524 mm
Min. bendable width: 150 mm
Max. bending height: 254 mm
Max. bending depth: 50 mm
Max. sheet rotation area: 3300 mm
Bending force: 500 to
Pressure force: 1000 to
Sheet thickness (420 N/mm²): 3.2 mm
Sheet thickness (600 N/mm²): 2.2 mm
Sheet thickness (260 N/mm²): 4 mm
Min. sheet thickness - mild steel: 0.5 mm
Max. bending angle: 135 °

Suitable for plates: 1
Max. bevel width: 66 mm
Bevel angle: 60 °
Spindle speed (load-free): 300-800 rpm
Feed speed: 0 - 1,2 mm/min
Max. cutting depth: 6 mm
Motor: 6.5 kW
Length: 1179 mm
Width: 853 mm
Height: 1524 mm
Weight: 320 kg

Suitable for plates: 1
Max. bevel width: 35 mm
Bevel angle: 60 °
Spindle speed (load-free): 2780 rpm
Plate thickness: 35 mm
Feed speed: 250 - 500 mm/min
Motor: 1.6 kW
Weight: 54 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 30 mm
Bevel angle: 60 °
Spindle speed (load-free): 500-2920 rpm
Bevel of tube outer edge: 50 - 150 m/min
Feed speed: 3 mm/min
Work piece height: 100 mm
Motor: 7.5 kW
Length: 200 mm
Width: 100 mm
Weight: 850 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 21 mm
Bevel angle: 60 °
Spindle speed (load-free): 2740-3290 rpm
Motor: 2.2 kW
Weight: 21 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 21 mm
Bevel angle: 60 °
Spindle speed (load-free): 1300-1560 rpm
Bevel of tube outer edge: 300 m/min
Motor: 1.6 kW
Length: 441 mm
Width: 366 mm
Height: 339 mm
Weight: 23 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 21 mm
Bevel angle: 60 °
Spindle speed (load-free): 2820 rpm
Motor: 1.1 kW
Weight: 20 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 18 mm
Bevel angle: 60 °
Bevel radius: 2-5 mm
Spindle speed (load-free): 1800-5850 rpm
Min. diameter of bevel: 40 mm
Motor: 2.2 kW
Length: 585 mm
Width: 156 mm
Height: 238 mm
Weight: 10 kg

Working width: 1300
Sheet thickness range - mild steel: 150 mm
Brush diameter: 150 mm
Vacuum area: 250x350 mm
Table height: 945 mm
Motor: 0.75 kW
Length: 1400 mm
Width: 1000 mm
Height: 1450 mm
Weight: 300 kg

Cutting length: 1530 mm
Max. thickness - mild steel: 16 mm
Max. thickness - stainless steel: 12 mm
Strokes: 7 1/min
Cutting angle: 3 °
Number of downholders: 8 pcs.
Back gauge: 500 mm
Motor power: 22.5 kW
Oiltank: 250 l
Table height: 950 mm
Length: 2350 mm
Width: 1400 mm
Height: 2000 mm
Weight: 5200 kg

Cutting length: 1280 mm
Max. thickness - mild steel: 16 mm
Max. thickness - stainless steel: 12 mm
Strokes: 8 1/min
Cutting angle: 3 °
Number of downholders: 7 pcs.
Back gauge: 500 mm
Motor power: 22.5 kW
Oiltank: 250 l
Table height: 950 mm
Length: 2100 mm
Width: 1400 mm
Height: 2000 mm
Weight: 5000 kg

Cutting length: 1530 mm
Max. thickness - mild steel: 12 mm
Max. thickness - stainless steel: 9 mm
Strokes: 8 1/min
Cutting angle: 3 °
Number of downholders: 8 pcs.
Back gauge: 500 mm
Motor power: 15 kW
Oiltank: 180 l
Table height: 950 mm
Length: 2200 mm
Width: 1200 mm
Height: 1800 mm
Weight: 3400 kg

Cutting length: 1280 mm
Max. thickness - mild steel: 12 mm
Max. thickness - stainless steel: 9 mm
Strokes: 9 1/min
Cutting angle: 3 °
Number of downholders: 7 pcs.
Back gauge: 500 mm
Motor power: 15 kW
Oiltank: 180 l
Table height: 950 mm
Length: 1950 mm
Width: 1200 mm
Height: 1800 mm
Weight: 3200 kg

Cutting length: 1030 mm
Max. thickness - mild steel: 10 mm
Max. thickness - stainless steel: 6 mm
Strokes: 10 1/min
Cutting angle: 3 °
Number of downholders: 7 pcs.
Back gauge: 5000 mm
Motor power: 11 kW
Oiltank: 100 l
Table height: 900 mm
Length: 1550 mm
Width: 1150 mm
Height: 1600 mm
Weight: 1900 kg

Cutting length: 1030 mm
Max. thickness - mild steel: 8 mm
Max. thickness - stainless steel: 5 mm
Strokes: 14 1/min
Cutting angle: 3 °
Number of downholders: 7 pcs.
Back gauge: 500 mm
Motor power: 7.5 kW
Oiltank: 100 l
Table height: 900 mm
Length: 1550 mm
Width: 1150 mm
Height: 1600 mm
Weight: 1800 kg

Cutting length: 1030 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Strokes: 14 1/min
Cutting angle: 3 °
Number of downholders: 7 pcs.
Back gauge: 500 mm
Motor power: 5.5 kW
Oiltank: 100 l
Table height: 900 mm
Length: 1550 mm
Width: 1150 mm
Height: 1600 mm
Weight: 1700 kg

Cutting length: 6080 mm
Max. thickness - mild steel: 13 mm
Max. thickness - stainless steel: 10 mm
Gap in side frame: 350 mm
Strokes: 10 1/min
Cutting angle: 0,5 - 2,5 °
Number of downholders: 29 pcs.
Pressure of downholder: 58 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 37 kW
Oiltank: 400 l
Support arms: 6 pcs.
Table height: 950 mm
Table width: 650 mm
Table length: 6375 mm
Length: 7400 mm
Width: 2200 mm
Total width with support arm und protection fence: 3700 mm
Height: 2900 mm
Weight: 33820 kg

Cutting length: 6080 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Gap in side frame: 350 mm
Strokes: 10 1/min
Cutting angle: 0,5 - 2 °
Number of downholders: 29 pcs.
Pressure of downholder: 20 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 22 kW
Oiltank: 200 l
Support arms: 5 pcs.
Table height: 900 mm
Table width: 630 mm
Table length: 6370 mm
Length: 7300 mm
Width: 2150 mm
Total width with support arm und protection fence: 3400 mm
Height: 2750 mm
Weight: 25500 kg

Cutting length: 3080 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Gap in side frame: 350 mm
Strokes: 20 1/min
Cutting angle: 0,5 - 2 °
Number of downholders: 16 pcs.
Pressure of downholder: 20 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 11 kW
Oiltank: 125 l
Support arms: 3 pcs.
Table height: 820 mm
Table width: 494 mm
Table length: 3280 mm
Length: 4100 mm
Width: 2050 mm
Total width with support arm und protection fence: 3650 mm
Height: 1950 mm
Weight: 7980 kg

Swing over bed: 500 mm
Distance between centers: 1500 mm
Centre height: 250 mm
Spindle bore: 80 mm
swing over cross slide: 300 mm
Width of bed: 400 mm
Spindle nose / DIN55027: 8
Spindle taper: 80 M
Spindle speed steps: 21
Spindle revs: Array rpm
Number of feeds: 120
Longitudinal feed range: 0.04 - 12 mm/r
Cross feed range: 0.02 - 6 mm/r
Number of threads: 64
Metric thread range: 0.5 - 120 mm
Inch thread range: Array Tpi
Module thread range: 0.125 - 30
DP thread range: Array
Cross slide travel: 315 mm
Top slide travel: 130 mm
Tailstock quill diameter: 90 mm
Tailstock quill taper: 5 MK
Tailstock travel: 230 mm
Motor power: 7 kW
Length: 3100 mm
Width: 1250 mm
Height: 1400 mm
Weight: 2820 kg

Cutting length: 150 mm
Max. thickness - mild steel: 6 mm
Length: 290 mm
Width: 90 mm
Height: 560 mm
Weight: 14 kg

Cutting length: 3100 mm
Max. thickness - mild steel: 16 mm
Max. thickness - stainless steel: 10 mm
Gap in side frame: 350 mm
Strokes: 10 1/min
Cutting angle: 2 °
Number of downholders: 14 pcs.
Pressure of downholder: 61 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 37 kW
Oiltank: 410 l
Support arms: 2 pcs.
Table height: 818 mm
Table width: 550 mm
Table length: 3580 mm
Length: 4550 mm
Width: 2250 mm
Total width with support arm und protection fence: 3825 mm
Height: 2250 mm
Weight: 15000 kg

Cutting length: 4100 mm
Max. thickness - mild steel: 13 mm
Max. thickness - stainless steel: 8 mm
Gap in side frame: 350 mm
Strokes: 8 1/min
Cutting angle: 1.75 °
Number of downholders: 18 pcs.
Pressure of downholder: 62 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 30 kW
Oiltank: 330 l
Support arms: 3 pcs.
Table height: 818 mm
Table width: 550 mm
Table length: 4520 mm
Length: 5350 mm
Width: 2250 mm
Total width with support arm und protection fence: 3650 mm
Height: 2250 mm
Weight: 16300 kg

Cutting length: 3100 mm
Max. thickness - mild steel: 13 mm
Max. thickness - stainless steel: 8 mm
Gap in side frame: 50 mm
Strokes: 13 1/min
Cutting angle: 1.75 °
Number of downholders: 16 pcs.
Pressure of downholder: 37 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 30 kW
Oiltank: 330 l
Support arms: 2 pcs.
Table height: 840 mm
Table width: 600 mm
Table length: 3550 mm
Length: 4280 mm
Width: 2300 mm
Total width with support arm und protection fence: 3600 mm
Height: 2350 mm
Weight: 12500 kg

Cutting length: 3100 mm
Max. thickness - mild steel: 10 mm
Max. thickness - stainless steel: 6 mm
Gap in side frame: 50 mm
Strokes: 13 1/min
Cutting angle: 1.5 °
Number of downholders: 16 pcs.
Pressure of downholder: 22 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 22 kW
Oiltank: 200 l
Support arms: 2 pcs.
Table height: 865 mm
Table width: 580 mm
Table length: 3515 mm
Length: 4200 mm
Width: 2250 mm
Total width with support arm und protection fence: 3600 mm
Height: 2100 mm
Weight: 9300 kg

Cutting length: 4100 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Gap in side frame: 50 mm
Strokes: 12 1/min
Cutting angle: 1.5 °
Number of downholders: 20 pcs.
Pressure of downholder: 17 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 15 kW
Oiltank: 200 l
Support arms: 3 pcs.
Table height: 865 mm
Table width: 580 mm
Table length: 4510 mm
Length: 5230 mm
Width: 2300 mm
Total width with support arm und protection fence: 3600 mm
Height: 2150 mm
Weight: 11460 kg

Max. thickness - mild steel: 4 mm
Throat depth: 200 mm
Tools: 4 pcs.
Rolls diameter: 126 mm
Motor: 2.2 kW
Revs: 16 1/min
Length: 1700 mm
Width: 570 mm
Height: 1200 mm
Weight: 500 kg
