ELB - SWN 5 VA II Flachschleifmaschine

-Schleifbereich X/Y/Z 525x375x255mm
-Magnetplatte 700x300mm
-Tischaufspannfläche 900x250mm
-Tischlängshub 10-625mm
-Tischbelastung max. 280Kg
-Tischvorschub 1-30 m/min
-Pendelschleifen 3-30 m/min
-Abstand - Tisch bis Spindelmitte 525mm
-Vertikal Vorschubgeschwindigkeit 2-180 mm/min
-Zustellgröße - regelbar 0,001-2mm
-Schleifscheibendrehzahl 3000 U/min
-Kühlmitteleinrichtung
-Maschinenfüße
-Dokumentation
-KOMPLETTE TECHNISCHE DATEN SIEHE FOTOS

Abmaße:
LxBxH 2,7x2,2x2 Meter / Gewicht 3500Kg

E.Büker - Typ N76 Endenbearbeitungsmaschine / Anfasmaschine

-Arbeitsbereich 6 - 76mm
-Drehzahl 10-1800 U/min
-Leistung 0,75 KW
-Unterbau
-Not-Aus

Abmaße:
LxBxH 0,7x0,5x1,4 Meter / Gewicht 250Kg

Rundtischschleifmaschine - DELTA LC 400

-CE-Kennung
-Magnetdurchmesser 400mm
-Schleifdurchmesser 400mm
-Zwei Geschwindigkeiten 20/40 U/min
-Schleifscheibendrehzahl 2850 U/min
-Schleifhöhe 220mm
-Höhenverstellung mittels Handrad
-Feinzustellung 0,01mm
-Abstand / Achse-Säule / Achse-Schleifscheibe 315mm
-Schleifscheibe Diamantschleifscheibe + Korundschleifscheiben
-Seitliche Abzieheinrichtung mit Abrichtdiamant
-Kühlmitteleinrichtung
-Maschinenumhausung
-Anschlußkabel
-Maschinenfüße
-Maschinendokumentation

Abmaße:
LxBxH 1,2x1x1,8 Meter / Gewicht 750Kg

Drilling capacy mild steel: 23 mm
Taper: MK 2
Distance spindle - column: 260 mm
Revs: 20 - 2000 r.p.m.
Motor: 1 kW
Tapping capacity: M16x1
Feeds: manual mm/r
Column diameter: 110 mm
Distance spindle - table: 230 - 850 mm
Table: 420 x 340 mm
Quill travel: 100 mm
Length: 430 mm
Width: 715 mm
Height: 1800 mm
Weight: 290 kg

Laser power: 3 kW
Manual table / shuttle table: Manual table
Max. thickness - mild steel: 16 mm
Max. thickness - stainless steel: 8 mm
Max. thickness - aluminium: 8 mm
Max. Application Range - Copper: 5 mm
Max. Application Range - Brass: 8 mm
Cutting area: 3.048 x 1.530 mm
X-axis: 3048 mm
Y-axis: 1530 mm
Z-Axis: 125 mm
Max. Sheet size: 3.048 x 1.524 mm
Max. sheet weight: 127 kg/m²
Max speed x-axes: 90 m/min
Max speed y-axes: 90 m/min
Max. speed simultaneous: 127 m/min
Max. acceleration: 14 m/s²
Positioning accuracy: +/- 0,05 mm
Repeat accuracy: +/- 0,05 mm
Total space length U: 5310 mm
Total space width G: 2810 mm
Height: 1860 mm
Weight: 6600 kg

Shaft diameter: 60
Rolls diameter: 177 mm
Driven rolls: 3
Motor power: 3.7 kW
Speed: 6 m/min
Flat steel vertical position (section / min. diameter): 70x10 mm / 600 mm, 30x10 mm / 250 mm
Flat steel horizontal position (section / min. diameter): 90x25 mm / 500 mm, 50x5 mm / 250 mm
Square bar (section / min. diameter): 40x40 mm / 500 mm, 20x20 mm / 300 mm
Round bar (section / min. diameter): Ø. 40 mm / 500 mm, Ø 20 mm / 300 mm
Tube (section / min. diameter): Ø 60x2 mm / 600 mm, Ø 20x1 / 250 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 80x40x3 mm
Form tube square (section / min. diameter): 60x60x4 mm
Angle leg outside (Querschnitt / min. Durchmesser): 50x5 mm / 1.000 mm, 30x4 mm / 350 mm
Angle leg inside (section / min. diameter): 50x5 mm / 500 mm, 30x3 mm / 250 mm
Length: 1160 mm
Width: 1000 mm
Height: 1175 mm
Weight: 1194 kg

Cutting length: 2050 mm
Max. thickness - mild steel: 4 mm
Strokes: 42 1/min
Back gauge: 750 mm
Motor power: 7.5 kW
Table height: 800 mm
Table width: 450 mm
Length: 2700 mm
Width: 2300 mm
Height: 1350 mm
Weight: 2800 kg

Working width: 1350
Sheet thickness range - mild steel: 0,6 - 170 mm
Grinding belt dimensions: 1120 x 2200 mm
Suction capacity: 4000 m³/h
Connection for dust collector diam.: 200 mm
Air connection: 6 bar
Noise level: 78 (+/-2) dB
Length: 1750 mm
Width: 2100 mm
Height: 2180 mm
Weight: 2000 kg

Length: 835 mm

Jaw opening: 200 mm
jaw height: 63 mm
Opening of upper beam: 160 mm

Jaw opening: 200 mm
jaw height: 62 mm
Opening of upper beam: 300 mm
Clamping Force: 8500 kg
Weight: 110 kg

pressing capacity: 70 to
Cylinder fix or moveable: horizontal moveable
Stroke: 350 mm
Daylight: 900 mm
Distance between columns: 1050 mm
Working speed: max. 9 mm/s
Motor power: 2 kW
Horizontal movable cylinder: 650 mm
Length: 1950 mm
Width: 1000 mm
Height: 2250 mm
Weight: 1220 kg

Flexion modulus: 19 cm³
Standard steel tube: 38 x 1,5 mm
Furniture tube: 38 x 1,5 mm
FE35 (for hydraulic tubes): 35 x 3 mm
Stainless steel AISI304-318: 30 x 2 mm
Stainless steel AISI308 (food industry): 35 x 1,5 mm
Brass soft: 42 x 1,5 mm
Hard copper and aluminium: 42 x 1,5 mm
Soft copper: 50 x 2 mm
Conduit tube (TAZ): 50 x 2 mm
Mepla, Gebereit and similar: 50 x 4 mm
Roundbar solid (S275JO): 20 mm
Squarebar solid (S275JO): 10 x 25 mm
Flatsteel solid (S275JO): 25 x 20 (stehend), 25 x 16 (stehend) mm
Max. bending radius: 180 mm
Min. bending radius: 36 mm
Min. tube Ø: 10 mm
Max. bending speed: 2 r/min
Motor: 0.9 kW
Length: 245 mm
Width: 300 mm
Height: 320 mm
Weight: 23 kg

Drilling capacy mild steel: 18 mm
Taper: MK 2
Distance spindle - column: 240 mm
Revs: 30 - 3000 r.p.m.
Tapping capacity: M12
Quill travel: 100 mm
Distance spindle - table: 155 - 415 mm
Distance spindle-base: 155 - 550 mm
Table: 340 x 280 mm
Column diameter: 82 mm
Length: 355 mm
Width: 705 mm
Height: 1065 mm
Weight: 170 kg

Horauf BDM Universal


Max cover dimensions:410 x 720 mm
Min cover dimenions: 170 x 105 mm

Cardboard thickiness min 1 mm to max 4 mm
Cover paper material: 80-120 g/m2

ang 470 PLC Ring Binder & Lever arch Assembly Line

High-performance automatic production line for ring binders
Brand: Hang
Year: 2007
Model: 470 PLC – FANUC Controlled

This fully automatic line is designed for efficient production of ring binders according to customer specifications. The machine is equipped with multiple processing stations and a Fanuc PLC control with touchscreen interface.

Main Components:

Sheet feeder (Saug-Anleger)
Creasing station
Gripping hole punching unit (Griffloch-Ösmaschine)
Double riveting station
Operator control panel (Fanuc QuickPanel View)
Mechanic feeding unit
Single riveting station
Folding station
Technical Specifications

PLC Control: FANUC with memory for up to 1000 programs and modem for remote support

Setup time: Approx. 2-3 minutes

Material Range:

Cover height: 120 – 400 mm
Cover width: 300 – 820 mm

Material thickness: Min. 1 mm – Max. 3.5 mm
Rivet spacing: 90 – 300 mm

Machine Condition

- In excellent working condition
-Touch panel with program counter, total counter and production statistics
- Fanuc QuickPanel View display
- Ready for immediate production
- Available for inspection in our warehouse

Production Counter Information (Machine Usage)

Day Counter: 250,895 cycles
Total Counter: 9,495,162 cycles
Product Counter: 1,336,482 units
Operating Time: 12,838 hours

Comefri NPA710200IE3 Centrifugal fan, 2017, 30Kw, see plates for spec, two in stock

Comefri NPA630RD Centrifugal fan, 2017, 7.5Kw, see plates for spec, two in stock

Teknomek Stainless cabinets, Various stainless cabinets on wheels

Teknomek Stainless bins, Various stainless bins

Teknomek stainless trolleys, Various sizes of stainless trolleys on wheels

Teknomek stainless tables, Various sizes of stainless tables on wheels

Danfoss Turbocor TT350 Compressor, Serial: 197023, 2019, Danfoss TT350-H1-ST-F-O-CE centrifugal compressor, Air and water cooled, low lift capacity, 70-120T / 246-421 Kw capacity

Guttridge Easyflo Mobile screw elevator, Serial: 326493, 2007, elevated screw conveyor, 100Kg stainless hopper, discharge height 1700mm, mobile

Guttridge Easyflo Mobile screw elevator, Serial: 58493811, 2014, Stainless, elevated screw conveyor, 100Kg stainless hopper, discharge height 1700mm, mobile

Guttridge Easyflo Mobile screw elevator, Elevated screw conveyor, 100Kg stainless hopper, discharge height 1620mm, mobile

Guttridge Easyflo Mobile screw elevator, Serial: 59961811, 2017, Stainless, elevated screw conveyor, 100Kg stainless hopper, with stainless dust free booth on hopper, discharge height 1700mm, mobile

Fryma Koruma MS65 Ball Mill, Serial: 102333, 2014, Stainless contact parts, 316 SS, double jacketed, previously running on nut butters at 1000 litres per hour, Siemens HMI touch screen controls, 3Ph

KEK Kibbler, Serial: 11818KIB, Stainless, Kek Kibbler pre breaker mill, ideal for coarse grinding, mounted on stainless frame, 7.5Kw motor, 80Kg stainless hopper, variable speed, comes with wheels, 3Ph

Polar Stainless conveyor 2017, stainless elevator conveyor, elevates from 250mm to 900mm, belt width 300mm, overall length 4000mm, with 50Kg hopper and side guides,

Cato PA160 Meat grinder, Serial: 327, Stainless, 300L hopper capacity, 160mm diameter throat, 15Kw, comes with various size mincing plates and brand new knives and drive belts, 3Ph

AMP Rose Coating pan Stainless, 500L coating pans, jacketed with test pressure 120Psi, with lids, 3Ph

Polar Tumbling drum 2017, Stainless, flavouring drum, overall length 2000mm, drum diameter 1000mm, 3Ph

Russell Finex 30048 separator, Serial: ML196, 2012, stainless decks and meshs, three deck sieve, diameter of deck 1150mm, 3Ph

Russell Finex 30510 separator, Serial: FS105, 2009, stainless decks and meshs, three deck sieve, diameter of deck 1150mm, 3Ph

GEA Niro NS2006P piston homogeniser, Serial: 12590, 2016, Stainless, Max Press. (Mpa) 25, rated flow rate 150 dm3/h, 3Ph

GEA Niro NS2006P piston homogeniser, Serial: 6233, 2005, Stainless, Max Press. (Mpa) 25, rated flow rate 150 dm3/h, 3Ph

Harland Sirius Mark 5 labeller, Serial: J31878, 2007, wrap around labeller, previously used for pots of tablets, belt dimensions 3500mm x 80mm, also has top mounted top labeller used for labelling the lids of pots, comes with Allen coder, HMI touch screen controls, 3Ph

Ram K60D Planetary mixer, Serial: 15099, 2015, 60L stainless bowl, with beater attachment, with adjustable timer and speed controls, safety guard, 3Ph

Blechbreite: 1250 mm
Blechstärke: 2 mm
Anbiegung: .
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: t
Raumbedarf ca.: m

Druck: 100 t
Abkantlänge: 3000 mm
Ständerweite: 2550 mm
Hub: 150 mm
Gesamtleistungsbedarf: kW
Betriebsstunden: . h
Maschinengewicht ca.: 8,3 t
Raumbedarf ca.: m

Bohrleistung in Stahl (Durchmesser): 32 mm
Ausladung: 640 mm
Werkstückhöhe - max.: . mm
Bohrleistung in Guss: 50 mm
Bohrleistung in St 60 - Aufbohren: . mm
Gewindeschneiden: .
Pinolendurchmesser: . mm
Spindelaufnahme MK: MT4
Drehzahl: 88-1500mm (6x) U/min
Vorschub: mm/U
Aufspannfläche: mm
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: t

Bohrleistung in Stahl (Durchmesser): . mm
Ausladung: 1250 mm
Werkstückhöhe - max.: . mm
Bohrleistung in Guss: 60 mm
Bohrleistung in St 60 - Aufbohren: . mm
Gewindeschneiden: .
Pinolendurchmesser: . mm
Spindelaufnahme MK: MT5
Drehzahl: 28-2.500 U/min
Vorschub: mm/U
Aufspannfläche: mm
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: t

Drilling capacy mild steel: 18 mm
Taper: MK 2
Distance spindle - column: 240 mm
Revs: 30 - 3000 r.p.m.
Tapping capacity: M12
Feeds: manual mm/r
Column diameter: 82 mm
Distance spindle - table: 180 - 870 mm
Table: 340 x 280 mm
Quill travel: 100 mm
Length: 705 mm
Width: 355 mm
Height: 1825 mm
Weight: 195 kg

Spindeldurchmesser: 250 mm
x-Weg: 12000 mm
y-Weg: 5850 mm
z-Weg: 1600 mm
w-Achse: 2000 mm
Steuerung: Siemens
Typ: 840 D Powerline
Drehzahl: 875 U/min
Traghülsenabmessung: 540x560 mm
Kühlmitteleinrichtung: 1800 l
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: 130 t

Drilling capacy mild steel: 30 mm
Taper: MK 3
Distance spindle - column: 300 mm
Revs: 0 - 4000 r.p.m.
Motor: 3 kW
Tapping capacity: M30x3,5
Feeds: 0,10 / 0,16 / 0,25 mm/r
Column diameter: 125 mm
Distance spindle - table: 150 - 700 mm
Table: 590 x 450 mm
Quill travel: 125 mm
Length: 900 mm
Width: 610 mm
Height: 1980 mm
Weight: 385 kg

Seriennummer: 966438 Nummer
Grad: 1 Grade
Code: 516-947 Nummer

Lagernummer: 1077-Z01441
Maschinenart: Messwerkzeug und Messmittel
Fabrikat: HOMMELWERKE
Typ: Sternmikrometer
Baujahr: -
Steuerung: konventionell
Lagerort: Dorsten
Ursprungsland: Deutschland
Lieferzeit: sofort
Frachtbasis: ab Standort
Preis: Auf Anfrage

Saw frame: Pivot frame
Band dimensions: 3120 x 27 x 0,9 mm
Band speed continous: 15 - 101 m/min
Cutting capacity 0° round: 280 mm
Cutting capacity 0° square: 240 mm
Cutting capacity 0° flat: 310 x 240 mm
Cutting capacity 45°: round 230 mm, square 230 mm, rectangular 230x230 mm
Cutting capacity 60°: round 140 mm, square 140 mm, rectangular 140x140 mm
Cutting capacity - 45°: round 200 mm, square 170 mm, rectangular 220x100 mm
Min. rest piece length: 240 mm
Working height: 835 mm
Hydraulic motor: 0.37 kW
Motor: 1 kW
Coolant pump motor: 0.12 kW
Torque feeding carriage motor: 1.95 Nm
Torque motor for automatic bow rotation: 1.95 Nm
Length: 5150 mm
Width: 3200 mm
Height: 1950 mm
Transport dimensions: 5000 x 2200 x 1900 mm
Weight: 2150 kg

Ref. no.: 18565
Hersteller: DEMAG
Year of construction: 2005

Clamping unit
Clamping force: 150 ton
Opening stroke: 500 mm
Distance between tie bars: 500 x 500 mm
Mould height min.: 250 mm
Opening width: 750 mm
Platen size (h x v): 750 x 750 mm

Injection unit
Screw diameter: 45 mm
Injection volume: 323 cm³
Shot weight: 290 g
Injection pressure: 1973 bar

Measurements and weight
Dimensions: 5.45 x 1.63 x 2.1 m
Machine weight: 7500 kg

Robot
Producer: Wittmann
Type: W721-0231
Year: 2005
