MKW 30 UT/20GS/AW/HV

Year 80/2000
20 stations collating machine
Complete with stitching unit type 50/SFT350
2 x Hohner 52-8 stitching heads.
and Jogger

Polar LW 1000-4 Stack Lift

Year: 2001
Platform 80 × 126 mm.
The lift automatically raises the material to an ergonomic working height, allowing the operator to easily load it into the jogger or directly into the cutting machine.
It can also be used for stacking the cut material.
No floor anchoring is required, so the unit is easy to relocate.
Equipped with continuously adjustable reflex light barriers for automatic lifting and lowering.

The control panel can be mounted on either the right or left side.

ang 470 PLC Ring Binder & Lever arch Assembly Line

High-performance automatic production line for ring binders
Brand: Hang
Year: 2007
Model: 470 PLC – FANUC Controlled

This fully automatic line is designed for efficient production of ring binders according to customer specifications. The machine is equipped with multiple processing stations and a Fanuc PLC control with touchscreen interface.

Main Components:

Sheet feeder (Saug-Anleger)
Creasing station
Gripping hole punching unit (Griffloch-Ösmaschine)
Double riveting station
Operator control panel (Fanuc QuickPanel View)
Mechanic feeding unit
Single riveting station
Folding station
Technical Specifications

PLC Control: FANUC with memory for up to 1000 programs and modem for remote support

Setup time: Approx. 2-3 minutes

Material Range:

Cover height: 120 – 400 mm
Cover width: 300 – 820 mm

Material thickness: Min. 1 mm – Max. 3.5 mm
Rivet spacing: 90 – 300 mm

Machine Condition

- In excellent working condition
-Touch panel with program counter, total counter and production statistics
- Fanuc QuickPanel View display
- Ready for immediate production
- Available for inspection in our warehouse

Production Counter Information (Machine Usage)

Day Counter: 250,895 cycles
Total Counter: 9,495,162 cycles
Product Counter: 1,336,482 units
Operating Time: 12,838 hours

D&K Europa System B2 Laminator automatic laminating machine

Technical data:
Max sheet size: 540mm x 740mm
Min sheet size: 210mm x 220mm
Min grammage: 115 gsm
Max grammage: 400 gsm
Operating temperature: 80-145°C
Weight: 750 kg
Power supply 380V
Steel, chrome-plated cylinder
Pneumatic pressure, separation and automatic feeding from a high stack.
Sheet feeding accuracy: ±2.0mm.
Touch panel for easy operation.
Sheet straightening module.

Citoborma 280

2 head paperdrill

Duplo Docucutter DC-645 Creaser, cutter

Stock A134R-R5PS6M / 1650 x 2050P Laming machine

Sheet to board laminating machine for producing displays and packing material

Horizon AC 8000 S collating machine

* collating stations
* suctions feeder
* jogger with cris cross

Sallmetal Laminating machine

S1050

Max Laminating size: 105 cm

Heidelberg SBB ( 56×82 cm) Gray cylinder

Very nice Heidelberg SBB cylinder

Fitted with safety covers with switches.
Electronics renewed.

Complete with 2 punch frames

Stock LM 123


A simple semi-automatic spot labeling machine suitable for running (labeling) substrate sheets, flat boxes, blanks, as well as pre-folded (RSC´s) with litho printed labels. Equipped with an automatic label feeder and take-off table. The label is mounted to the lower side of the substrate sheet.

Label Feeder (4E): Suction feeder, for automatically feeding of the labels. The labels have to be pre-loaded on the pile board by hand. Pre-loading height: approx. 7.8”. On sheet removal the pile is re-timing automatically. A suction bar is separating the labels at their front edge, always sucking a single sheet and transporting it into the machine.

Label Registering Unit (LM-1) includes a timed suction conveyor that incorporates a separate motor drive that takes the glued labels after leaving the gluing unit and automatically registers the labels. Precise registration is achieved utilizing the unit’s adjustable side and rear edge guides that are set to the dimensions required for the proper registration of the corrugated sheet or box.

A 2-cylinder gluing unit is utilized for glue application and metering roller with stripping needles. The glue is applied to the label that is then stripped off the application roller by special stripping needles. The litho printed label will always be glued. The Model LM includes an automatic glue-feeding system with diaphragm pump (P).

Squeeze roller that presses the labelled sheets and blanks together.
Integrated sensor for detecting and registering the glued label
Label registering unit for placing and applying the corrugated blank to the glued label
Manual feeding of the corrugated blank or box pressure roller
Take-off table for the manual take-off of the labeled sheets / blanks.
Integrated sheet counter.
Siemens PLC control.
Suction belt

GTS Countmaster 1053

With stoke inserter

230 volt
Max stack height: 140 mm
Max paper size: 350 x 600 mm
Min paper size: 45

Workingwidth 1500 mm

Substrate Feeder automatic suction feeder
Laminate Feeder by hand
Details with pressing roll, with pressing belt
Delivery table
Available Direct

Cauhe VA ( 1450 x 1850 mm ) die cutting machine
Model VA
Year of construction 2000

Automatic closing window

Hardened die plate

Theisen en Bonitz Sprint HP 320

20 stations High pile collating machine
Complete with pumps

Theisen & Bonitz 303 stitching unit
Equipped with 2 Hohner stitching heads and delivery belt.
Max format: 350 x 50 cm
