Sheet metal working machinesRound rolling machines

Hydraulic 4-roll plate bending machine HESSE by SAHINLER 4R

HESSE by SAHINLER 4R HS 20-200
Bending length: 2050 mm Max. bending capacity - mild steel: 10 Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 10 mm Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 8 mm Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 8 mm Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 6 mm Upper roll diameter: 200 - 220 mm Lower roll diameter: 200 - 220 mm Lateral roll diameter: 160 mm Bending speed: 1,5 / 6 m/min Motor power: 5.5 kW Length: 4400 mm Width: 1150 mm Height: 1250 mm Weight: 3950 kg
Bending length: 2050 mm
Max. bending capacity - mild steel: 10
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 10 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 8 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 8 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 6 mm
Upper roll diameter: 200 - 220 mm
Lower roll diameter: 200 - 220 mm
Lateral roll diameter: 160 mm
Bending speed: 1,5 / 6 m/min
Motor power: 5.5 kW
Length: 4400 mm
Width: 1150 mm
Height: 1250 mm
Weight: 3950 kg
5
Sheet metal working machinesRound rolling machines

Hydraulic 4-roll plate bending machine HESSE by SAHINLER 4R

HESSE by SAHINLER 4R HS 20-180
Bending length: 2050 mm Max. bending capacity - mild steel: 8 Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 8 mm Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 6 mm Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 6 mm Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 4 mm Upper roll diameter: 180 mm Lower roll diameter: 180 mm Lateral roll diameter: 150 mm Bending speed: 1,5 / 6 m/min Motor power: 5.5 kW Length: 4400 mm Width: 1150 mm Height: 1250 mm Weight: 3790 kg
Bending length: 2050 mm
Max. bending capacity - mild steel: 8
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 8 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 6 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 6 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 4 mm
Upper roll diameter: 180 mm
Lower roll diameter: 180 mm
Lateral roll diameter: 150 mm
Bending speed: 1,5 / 6 m/min
Motor power: 5.5 kW
Length: 4400 mm
Width: 1150 mm
Height: 1250 mm
Weight: 3790 kg
5
Sheet metal working machinesRound rolling machines

Motorized 4-roll plate bending machine HESSE by ISITAN 4R HM

HESSE by ISITAN 4R HMS 1550x130
Bending length: 1550 mm Max. bending capacity - mild steel: 4.5 Max. plate thickness without prebending - mild steel: 4.5 mm Max. plate thickness with prebending - mild steel: 3.5 mm Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 4.5 mm Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 3.5 mm Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 3.5 mm Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 2.5 mm Upper roll diameter: 130 mm Lower roll diameter: 130 mm Lateral roll diameter: 130 mm Bending speed: 5 m/min Motor power: 2,2 + 1,1 kW Length: 3300 mm Width: 1150 mm Height: 1110 mm Weight: 2370 kg
Bending length: 1550 mm
Max. bending capacity - mild steel: 4.5
Max. plate thickness without prebending - mild steel: 4.5 mm
Max. plate thickness with prebending - mild steel: 3.5 mm
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 4.5 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 3.5 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 3.5 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 2.5 mm
Upper roll diameter: 130 mm
Lower roll diameter: 130 mm
Lateral roll diameter: 130 mm
Bending speed: 5 m/min
Motor power: 2,2 + 1,1 kW
Length: 3300 mm
Width: 1150 mm
Height: 1110 mm
Weight: 2370 kg
1
Sheet metal working machinesRound rolling machines

Hydraulic 4-roll plate bending machine HESSE by ISITAN 4RH 1

HESSE by ISITAN 4RH 10x90
Bending length: 1050 mm Max. bending capacity - mild steel: 2.5 Max. plate thickness without prebending - mild steel: 2.5 mm Max. plate thickness with prebending - mild steel: 2 mm Upper roll diameter: 90 mm Bending speed: 4 m/min Motor power: 2.2 kW Length: 2250 mm Width: 1000 mm Height: 1500 mm Weight: 900 kg
Bending length: 1050 mm
Max. bending capacity - mild steel: 2.5
Max. plate thickness without prebending - mild steel: 2.5 mm
Max. plate thickness with prebending - mild steel: 2 mm
Upper roll diameter: 90 mm
Bending speed: 4 m/min
Motor power: 2.2 kW
Length: 2250 mm
Width: 1000 mm
Height: 1500 mm
Weight: 900 kg
5
Sheet metal working machinesRound rolling machines

Hydraulic 4-roll plate bending machine HESSE by SAHINLER 4R

HESSE by SAHINLER 4R HS 15-220
Bending length: 1550 mm Max. bending capacity - mild steel: 12 Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 12 mm Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm Upper roll diameter: 220 mm Lower roll diameter: 200 mm Lateral roll diameter: 160 mm Bending speed: 1,5 / 6 m/min Motor power: 5.5 kW Length: 3900 mm Width: 1150 mm Height: 1250 mm Weight: 3600 kg
Bending length: 1550 mm
Max. bending capacity - mild steel: 12
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 12 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm
Upper roll diameter: 220 mm
Lower roll diameter: 200 mm
Lateral roll diameter: 160 mm
Bending speed: 1,5 / 6 m/min
Motor power: 5.5 kW
Length: 3900 mm
Width: 1150 mm
Height: 1250 mm
Weight: 3600 kg
5
Sheet metal working machinesRound rolling machines

Hydr. 4-roll bending machine HESSE by SAHINLER 4R HS 25-260

HESSE by SAHINLER 4R HS 25-260
Bending length: 2550 mm Max. bending capacity - mild steel: 13 Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 13 mm Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm Upper roll diameter: 260 mm Lower roll diameter: 260 mm Lateral roll diameter: 200 mm Bending speed: 1,5-6 m/min Motor power: 7.5 kW Length: 4800 mm Width: 1600 mm Height: 1550 mm Weight: 6800 kg
Bending length: 2550 mm
Max. bending capacity - mild steel: 13
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 13 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm
Upper roll diameter: 260 mm
Lower roll diameter: 260 mm
Lateral roll diameter: 200 mm
Bending speed: 1,5-6 m/min
Motor power: 7.5 kW
Length: 4800 mm
Width: 1600 mm
Height: 1550 mm
Weight: 6800 kg
2
Sheet metal working machinesRound rolling machines

Motor operated 3-roll plate bending machine HESSE by ISITAN

HESSE by ISITAN IRM 2050 x 140
Bending length: 2050 mm Max. bending capacity - mild steel: 4 Upper roll diameter: 140 mm Motor power: 2.2 kW Length: 3200 mm Width: 750 mm Height: 1000 mm Weight: 1650 kg
Bending length: 2050 mm
Max. bending capacity - mild steel: 4
Upper roll diameter: 140 mm
Motor power: 2.2 kW
Length: 3200 mm
Width: 750 mm
Height: 1000 mm
Weight: 1650 kg
2
Sheet metal working machinesRound rolling machines

Hydraulic 4-roll plate bending machine HESSE by DURMA HRB-4

HESSE by DURMA HRB-4 20240
Bending length: 2050 mm Max. bending capacity - mild steel: 13 Max. plate thickness with prebending - mild steel: 10 mm Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 13 mm Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm Upper roll diameter: 240 mm Lower roll diameter: 240 mm Lateral roll diameter: 190 mm Working height: 820 mm Motor power: 11 kW Length: 3830 mm Width: 1160 mm Height: 1200 mm Weight: 5000 kg
Bending length: 2050 mm
Max. bending capacity - mild steel: 13
Max. plate thickness with prebending - mild steel: 10 mm
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 13 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm
Upper roll diameter: 240 mm
Lower roll diameter: 240 mm
Lateral roll diameter: 190 mm
Working height: 820 mm
Motor power: 11 kW
Length: 3830 mm
Width: 1160 mm
Height: 1200 mm
Weight: 5000 kg
2
Sheet metal working machinesRound rolling machines

Motorized 3-roll plate bending machine HESSE by ISITAN IRM 1

HESSE by ISITAN IRM 1050 x 130
Bending length: 1050 mm Max. bending capacity - mild steel: 5 Upper roll diameter: 130 mm Bending speed: 3 m/min Motor power: 2.2 kW Length: 2200 mm Width: 750 mm Height: 1000 mm Weight: 1200 kg
Bending length: 1050 mm
Max. bending capacity - mild steel: 5
Upper roll diameter: 130 mm
Bending speed: 3 m/min
Motor power: 2.2 kW
Length: 2200 mm
Width: 750 mm
Height: 1000 mm
Weight: 1200 kg
