Spindeldurchmesser: 110 mm
x-Weg: 2000 mm
y-Weg: 1200 mm
Spindeldrehzahlen: 6-1250 U/min
Tischfläche: 1400x900 mm
Spindelantriebmotor: 12 kW
Spindelaufnahme ISO: 50
Spindelweg: 800 mm
z-Weg: 1000 mm
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: 20 t
Raumbedarf ca.: 5x3x2 m

Saw frame: Double column
Band dimensions: 6800x41x1,3 mm
Band speed continous: 20-100 m/min
Cutting capacity 0° round: 560 mm
Cutting capacity 0° square: 540 mm
Cutting capacity 0° flat: 820x540 mm
Cutting capacity 45°: rund 550 mm, quadrat 540 mm, rechteck 550 x 540 mm
Cutting capacity 60°: rund 360 mm, quadrat 360 mm, rechteck 360 x 540 mm
Cutting capacity - 45°: rund 550 mm, quadrat 540 mm, rechteck 550 x 540 mm
Working height: 880 mm
Coolant pump motor: 0.12 kW
Hydraulic motor: 0.37 kW
Motor: 4 kW
Length: 3800 mm
Width: 1750 mm
Height: 2350 mm
Weight: 3200 kg

Cutting length: 2050 mm
Max. thickness - mild steel: 4 mm
Strokes: 42 1/min
Back gauge: 750 mm
Motor power: 7.5 kW
Table height: 800 mm
Table width: 450 mm
Length: 2700 mm
Width: 2300 mm
Height: 1350 mm
Weight: 2800 kg

Punching power: 110 ton
Throat depth: 500 mm
Max. diameter at sheet thickness (mild steel): 40x20 mm
Max. number of strokes at 20 mm stroke: 28 1/min
Motor: 9 kW
Length: 2080 mm
Width: 1300 mm
Height: 2050 mm
Weight: 3150 kg

Ref. no.: 18383
Hersteller: DEMAG
Year of construction: 2008

Clamping unit
Clamping force: 420 ton
Opening stroke: 770 mm
Distance between tie bars: 820 X 820 mm
Mould height min.: 380 mm
Mould height max.: 825 mm
Platen size (h x v): 1200 X 1100 mm

Injection unit
Screw diameter: 60 mm
Injection volume: 890 cm³
Shot weight: 810 g
Injection pressure: 2420 bar

Measurements and weight
Dimensions: 8,2 X 2,2 X 2,4 m
Machine weight: 22300 kg

Additional information & extras
Core pull: 4 pcs
Air valve: 7 pcs
Hot runner systems: 8 pcs.

Robot
Producer: Remak
Year: 2008

Nilpeter FA 2400

Hot air drying + 4 UV units
Die cutting unit
Turning bar


Print Cylinders:

120 z x 6
117 z x 4
113 z x 5
110 z x 5
106 z x 5
102 z x 5
100 z x 5
96 z x 5
93 z x 5
90 z x 5
88 z x 5
84 z x 5
80 z x 6
76 z x 6
74 z x 4
72 z x 4
70 z x 6
68 z x 6
64 z x 5
62 z x 5
60 z x 5
58 z x 5

Print cilinder Shafts: 21

Anilox rollers:
180 - 9 pieces
140 - 6 pieces
120 - 9 pieces
320/5 - 2 pieces
80 R - 1 piece
GTTR 2 pieces

Rubber rollers 13

Ink trays: 10

Distance spindle - table: 730 mm
Table: 1200 x 600 mm
Grinding lenght: 1200 mm
Magnetic table: 1200 x 600 mm
Table movement hydraulic: 1300 mm
Table speed: 5 - 30 m/min
Cross feed: 0-2250 m/min
Cross feed incremental: 0,001-32 mm
Max. cross feed: 685 mm
Automatic vertical feed: 560 mm
Vertical feed: 0-675 mm/min
Spindle revs: 500-2200 rpm
Spindle motor: 11 kW
Hydraulic motor: 5.5 kW
Cross feed motor: 3.1 kW
Feed motor grinding wheel: 3.1 kW
Max. workpiece weight on magnetic table: 1150 kg
Max. workpiece weight on t-slot table: 1600 kg
Grinding wheel dimensions: 405 x 75 x 127 mm
Length: 4790 mm
Width: 3207 mm
Height: 2305 mm
Weight: 8100 kg

Swing over bed: 630 mm
Distance between centers: 2000 mm
Centre height: 315 mm
Spindle bore: 103 mm
swing over cross slide: 430 mm
Width of bed: 400 mm
Spindle nose / DIN55027: 11
Spindle taper: 120 M
Spindle speed steps: 21
Spindle revs: Array rpm
Number of feeds: 120
Longitudinal feed range: 0.04 - 12 mm/r
Cross feed range: 0.02 - 6 mm/r
Metric thread range: 0.5 - 120 mm
Inch thread range: 60 - 1/4 Tpi
Module thread range: 0.125 - 30
DP thread range: Array
Cross slide travel: 315 mm
Top slide travel: 90 mm
Tailstock quill diameter: 90 mm
Tailstock quill taper: 5 MK
Tailstock travel: 230 mm
Motor power: 11 kW
Weight: 3310 kg

Shaft diameter: 35
Upper roll diameter: 137 mm
Lower roll diameter: 137 mm
Driven rolls: 3
Motor power: 1.1 kW
Speed: 7 m/min
Flat steel vertical position (section / min. diameter): 35x8 mm / 300 mm
Flat steel horizontal position (section / min. diameter): 50x12 mm / 400 mm
Square bar (section / min. diameter): 18x18 mm / 250 mm
Round bar (section / min. diameter): Ø 22 mm / 200 mm
Tube (section / min. diameter): Ø 40x1,5 mm / 500 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 30x15x2,5 mm / 500 mm
Form tube square (section / min. diameter): 25x25x2 mm / 450 mm
Angle leg outside (Querschnitt / min. Durchmesser): 35x35x5 mm / 400 mm
Angle leg inside (section / min. diameter): 30x30x4 mm / 550 mm
Length: 1050 mm
Width: 500 mm
Height: 1250 mm
Weight: 350 kg

Shaft diameter: 30
Upper roll diameter: 148 mm
Lower roll diameter: 118 mm
Driven rolls: 2
Motor power: 0.7 / 0,85 kW
Speed: 2/4 m/min
Flat steel vertical position (section / min. diameter): 50x10 mm / 1.800 mm, 20x6 mm / 300 mm
Flat steel horizontal position (section / min. diameter): 80x15 mm / 700 mm, 30 x 6 mm / 400 mm
Square bar (section / min. diameter): 30x30 mm / 900 mm, 10x10 mm / 200 mm
Round bar (section / min. diameter): Ø 30 mm / 900 mm, Ø 10 mm / 200 mm
Tube (section / min. diameter): Ø 60x1,5 mm / 1.000 mm, Ø 25x1,5 mm / 600 mm, 1 1/2"x2,9 mm / 600 mm, 1/4"x1,8 mm / 300 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 50x30x3 mm / 1.200 mm, 40x20x2 mm / 800 mm
Form tube square (section / min. diameter): 40x40x3 mm / 1.200 mm, 30x30x2 mm / 800 mm
Angle leg outside (Querschnitt / min. Durchmesser): 40x40x5 mm / 600 mm, 30x30x4 mm / 300 mm
Angle leg inside (section / min. diameter): 35x35x5 mm / 600 mm, 30x30x4 mm / 400 mm
Length: 600 mm
Width: 800 mm
Height: 1450 mm
Weight: 220 kg

Theisen en Bonitz Sprint B312 VP ( 2008)

Year: 2008
- 12 stations
– format: min. 7x10cm, max. 35x50cm
– paper weight: 18-800g/qm

Complete with QSM 304 stitching - folding- 3 side trimming unit
Equiped with hohner stithing heads
Loops stitching heads available

In mint condition !

Swing over bed: 760 mm
Distance between centers: 3000 mm
Centre height: 380 mm
Spindle bore: 132 mm
swing over cross slide: 520 mm
Width of bed: 560 mm
Spindle nose / DIN55027: 11
Spindle taper: 140 M
Revs continuous variable in gear steps: 3
Revs continuous variable: 7 - 42, 28 - 170, 165 - 1.015 rpm
Number of feeds: 150
Longitudinal feed range: 0.039 - 18 mm/r
Cross feed range: 0.02 - 9 mm/r
Metric thread range: 0.5 - 180 mm
Inch thread range: 60 - 1/6 Tpi
Module thread range: 0.125 - 45
DP thread range: Array
Cross slide travel: 410 mm
Top slide travel: 150 mm
Tailstock quill diameter: 105 mm
Tailstock quill taper: 6 MK
Tailstock travel: 225 mm
Motor power: 15 kW
Weight: 4470 kg

Swing over bed: 600 mm
Distance between centers: 2000 mm
Centre height: 300 mm
Spindle bore: 80 mm
swing over cross slide: 400 mm
Width of bed: 400 mm
Spindle nose / DIN55027: 8
Spindle taper: 90 M
Revs continuous variable in gear steps: 3
Revs continuous variable: 8-62, 62-500, 250-2.000 rpm
Number of feeds: 160
Number of threads: 64
Metric thread range: 0.5 - 120 mm
Inch thread range: 120 - 1/4 Tpi
Module thread range: 0.125 - 30
Cross slide travel: 315 mm
Top slide travel: 130 mm
Tailstock quill diameter: 90 mm
Tailstock quill taper: 5 MK
Tailstock travel: 230 mm
Motor power: 11 kW
Length: 3600 mm
Width: 1500 mm
Height: 1650 mm
Weight: 3110 kg

Distance spindle - table: 445 mm
Table: 460 x 200 mm
Grinding lenght: 460 mm
Magnetic table: 450 x 200 mm
Table speed: 0,1 - 25 m/min
Cross feed: 0 - 3000 m/min
Max. cross feed: 220 mm
Automatic vertical feed: 340 mm
Vertical feed: 0 - 3000 mm/min
Vertical feed incremental: 0.001 mm
Spindle revs: 1000 - 7000 rpm
Spindle motor: 3 kW
Hydraulic motor: 0.7 kW
Cross feed motor: 1.1 kW
Feed motor grinding wheel: 1.1 kW
Table height: 1015 mm
Max. workpiece weight on magnetic table: 175 kg
Max. workpiece weight on t-slot table: 210 kg
Grinding wheel dimensions: Dm. 205 x 12,7 x 31,75 mm
Length: 2510 mm
Width: 2515 mm
Height: 2010 mm
Weight: 1550 kg

Bending length: 2050 mm
Max. bending capacity - mild steel: 10
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 10 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 8 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 8 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 6 mm
Upper roll diameter: 200 - 220 mm
Lower roll diameter: 200 - 220 mm
Lateral roll diameter: 160 mm
Bending speed: 1,5 / 6 m/min
Motor power: 5.5 kW
Length: 4400 mm
Width: 1150 mm
Height: 1250 mm
Weight: 3950 kg

Bending length: 2050 mm
Max. bending capacity - mild steel: 8
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 8 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 6 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 6 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 4 mm
Upper roll diameter: 180 mm
Lower roll diameter: 180 mm
Lateral roll diameter: 150 mm
Bending speed: 1,5 / 6 m/min
Motor power: 5.5 kW
Length: 4400 mm
Width: 1150 mm
Height: 1250 mm
Weight: 3790 kg

Saw frame: Double column
Band dimensions: 8200x41x1,3 mm
Band speed continous: 20-100 m/min
Cutting capacity 0° round: 810 mm
Cutting capacity 0° square: 750 mm
Cutting capacity 0° flat: 910x750 mm
Cutting capacity 45°: rund 600 mm, quadrat 600 mm, rechteck 750 x 600 mm
Cutting capacity 60°: rund 360 mm, quadrat 360 mm, rechteck 750 x 360 mm
Working height: 725 mm
Coolant pump motor: 0.12 kW
Motor: 4 kW
Length: 4020 mm
Width: 1600 mm
Height: 2450 mm
Weight: 3970 kg

Ref. no.: 18368
Hersteller: ARBURG
Year of construction: 1997

Clamping unit
Clamping force: 50 ton
Opening stroke: 350 mm
Distance between tie bars: 320 X 320 mm
Mould height min.: 300 mm
Mould height max.: 550 mm
Platen size (h x v): 446 X 446 mm

Injection unit
Screw diameter: 30 mm
Injection volume: 85 cm³
Shot weight: 75 g
Injection pressure: 2200 bar

Measurements and weight
Dimensions: 3,25 x 1.15 x 2,0 m
Machine weight: 2250 kg

Distance spindle - table: 850 mm
Table: 1000 x 600 mm
Grinding lenght: 1000 mm
Magnetic table: 1000 x 600 mm
Table movement hydraulic: 1000 mm
Table speed: 5 - 25 m/min
Cross feed: 1250 m/min
Max. cross feed: 690 mm
Automatic vertical feed: max. 400 mm/min mm
Vertical feed: 400 mm/min
Vertical feed incremental: 0.001 mm
Spindle revs: 1450 rpm
Spindle motor: 11 kW
Hydraulic motor: 3.7 kW
Cross feed motor: 0.37 kW
Total power: 20 kW
Maximal table load: 1500 kg
Max. workpiece weight on magnetic table: 1120 kg
Max. workpiece weight on t-slot table: 1500 kg
Grinding wheel dimensions: 355 x 75 x 127 mm
Length: 3700 mm
Width: 4000 mm
Height: 3250 mm
Weight: 7400 kg

Working width: 650
Sheet thickness range - mild steel: 0,5 - 170 mm
Grinding belt dimensions: 670 x 2200 mm
Suction capacity: 4000 m³/h
Connection for dust collector diam.: 120 mm
Air connection: 6 bar
Noise level: 83 dB
Motor: 22 kW
Length: 2600 mm
Width: 1350 mm
Height: 2100 mm
Weight: 1125 kg

Distance spindle - table: 600 mm
Table: 400 x 1000 mm
Grinding area: 1.015 x 405 x 610 mm
Grinding lenght: 1015 mm
Magnetic table: 1000 x 400 mm
Max. work piece weight: 670 kg
Table movement hydraulic: 1100 mm
Table speed: 5 - 25 m/min
Cross feed: 0 - 2,250 m/min
Cross feed incremental: 3 - 32 mm
Max. cross feed: 450 mm
Automatic vertical feed: 440 mm
Vertical feed: 0 - 675 mm/min
Vertical feed incremental: 0.001 - 0.04 mm
Spindle revs: 500 - 2.000 rpm
Spindle motor: 5 kW
Hydraulic motor: 1.5 kW
Cross feed motor: 1.1 kW
Feed motor grinding wheel: 1.1 kW
Max. workpiece weight on magnetic table: 423 kg
Max. workpiece weight on t-slot table: 670 kg
Grinding wheel dimensions: 355 x 50 x 127 mm
Length: 3630 mm
Width: 2682 mm
Height: 2200 mm
Transport dimensions: 4550 x 2280 x 2530 mm mm
Weight: 4800 kg

pressing capacity: 150 to
Cylinder fix or moveable: fix
Stroke: 300 mm
Daylight: 610 mm
Distance between columns: 1020 mm
Rapid speed: 9 mm/s
Working speed: 5 mm/s
Retraction speed: 10 mm/s
Table: 600x1020 mm
Hole in table: 100 mm
Hole distance: 190 mm
Length: 2110 mm
Width: 1000 mm
Height: 2470 mm
Weight: 2450 kg

pressing capacity: 175 to
Bending length: 3050 mm
Axes: Y1 / Y2 / X and R axis
Stroke: 265 mm
Inside distance between side frames: 2600 mm
Gap in side frame: 410 mm
Daylight: 530 mm
Power concept: hydraulic
rapid speed Y-axis: 200 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 200
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 104 mm
Motor power: 2x4 kW
Length: 4250 mm
Width: 1700 mm
Height: 2750 mm
Weight: 10900 kg

pressing capacity: 15 to
Tonnage rating point: 1.4 mm
Table length: 320 mm
Table width: 490 mm
Hole in table: 130 mm
Stroke: 1 - 40 mm
Strokes: 200 1/min
Ram guides: 4
Ram adjustment: 40 mm
Ram hole: 30 mm
Throat depth: 200 mm
Daylight: 215 mm
Motor: 1.5 kW
Length: 1160 mm
Width: 1180 mm
Height: 1730 mm
Weight: 922 kg

Punching power: 50 ton
Throat depth: 130 mm
Max. diameter at sheet thickness (mild steel): 13/27 mm
Max. number of strokes at 20 mm stroke: 23 1/min
Motor: 3 kW
Length: 1100 mm
Width: 900 mm
Height: 1550 mm
Weight: 355 kg

Punching power: 80 ton
Throat depth: 510 mm
Max. diameter at sheet thickness (mild steel): 40x14 mm
Max. number of strokes at 20 mm stroke: 40 1/min
Motor: 9 kW
Length: 1700 mm
Width: 1300 mm
Height: 2050 mm
Weight: 1715 kg

Punching power: 55 ton
Throat depth: 750 mm
Max. diameter at sheet thickness (mild steel): 40x14 mm
Max. number of strokes at 20 mm stroke: 37 1/min
Motor: 9 kW
Length: 1930 mm
Width: 1200 mm
Height: 1800 mm
Weight: 1885 kg

Sheet Thickness - mild steel: 0.4 - 2 mm
Max. sheet width: 600 mm
Max. cross-section: 600x2 mm
Feed roll diameter: 80 mm
Motor torque: 10 Nm

Sheet Thickness - mild steel: 0.4 - 3 mm
Max. sheet width: 400 mm
Max. cross-section: 400x3 mm
Feed roll diameter: 80 mm
Motor torque: 10 Nm

Bending length: 350 - 2800 mm
Max. sheet length: 3050 mm
Max. sheet width: 1524 mm
Min. bendable width: 150 mm
Max. bending height: 254 mm
Max. bending depth: 50 mm
Max. sheet rotation area: 3300 mm
Bending force: 500 to
Pressure force: 1000 to
Sheet thickness (420 N/mm²): 3.2 mm
Sheet thickness (600 N/mm²): 2.2 mm
Sheet thickness (260 N/mm²): 4 mm
Min. sheet thickness - mild steel: 0.5 mm
Max. bending angle: 135 °

Suitable for plates: 1
Max. bevel width: 66 mm
Bevel angle: 60 °
Spindle speed (load-free): 300-800 rpm
Feed speed: 0 - 1,2 mm/min
Max. cutting depth: 6 mm
Motor: 6.5 kW
Length: 1179 mm
Width: 853 mm
Height: 1524 mm
Weight: 320 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 30 mm
Bevel angle: 60 °
Spindle speed (load-free): 500-2920 rpm
Bevel of tube outer edge: 50 - 150 m/min
Feed speed: 3 mm/min
Work piece height: 100 mm
Motor: 7.5 kW
Length: 200 mm
Width: 100 mm
Weight: 850 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 21 mm
Bevel angle: 60 °
Spindle speed (load-free): 2740-3290 rpm
Motor: 2.2 kW
Weight: 21 kg

Suitable for plates: 1
Suitable for tubes: 1
Max. bevel width: 21 mm
Bevel angle: 60 °
Spindle speed (load-free): 2820 rpm
Motor: 1.1 kW
Weight: 20 kg

Saw frame: Pivot frame
Band dimensions: 3120x27x0,9 mm
Band speed continous: 20-100 m/min
Cutting capacity 0° round: 280 mm
Cutting capacity 0° square: 240 mm
Cutting capacity 0° flat: 310x240 mm
Cutting capacity 45°: rund 230 mm, quadrat 230 mm, rechteck 230 x 230 mm
Cutting capacity 60°: rund 140 mm, quadrat 140 mm, rechteck 140 x 140 mm
Cutting capacity - 45°: rund 200 mm, quadrat 170 mm, rechteck 220 x 100 mm
Min. rest piece length: 240 mm
Working height: 835 mm
Coolant pump motor: 0.12 kW
Hydraulic motor: 0.37 kW
Motor: 1.5 kW
Torque feeding carriage motor: 1.95 Nm
Torque motor for automatic bow rotation: 1.95 Nm
Length: 2800 mm
Width: 2000 mm
Height: 1820 mm
Weight: 1200 kg

Flexion modulus: 6 cm³
Round tube: Ø 60 x 2 mm
Standard steel tube: 50 x 3,31 mm
Gas tube: Ø 1”1/4 x 80 mm
Stainless steel: Ø 50 x 2 mm
Hard copper and aluminium: Ø 64 x 2 mm
Square tube: Ø 40 x 40 x 3 mm
Rect. tube easy way: 25 x 50 x 6 mm
Rect. tube hard way: 50 x 25 x 2,7 mm
Rect. tube: Ø 50 x 25 x 3 mm bzw. Ø 25 x 50 x 6 mm
Max. outer diameter: 64 mm
Max. bending radius: 200 mm
Min. bending radius: 20 mm
Max. bending angle: 210 °
Speed: 1,25 / 2,5
Motor: 3.5 kW
Hydraulic oil capacity: 50 l
Length: 4000 mm
Width: 950 mm
Height: 1250 mm
Weight: 430 kg

Flexion modulus: 19 cm³
Standard steel tube: 38 x 1,5 mm
Furniture tube: 38 x 1,5 mm
FE35 (for hydraulic tubes): 35 x 3 mm
Stainless steel AISI304-318: 30 x 2 mm
Stainless steel AISI308 (food industry): 35 x 1,5 mm
Brass soft: 42 x 1,5 mm
Hard copper and aluminium: 42 x 1,5 mm
Soft copper: 50 x 2 mm
Conduit tube (TAZ): 50 x 2 mm
Mepla, Gebereit and similar: 50 x 4 mm
Roundbar solid (S275JO): 20 mm
Squarebar solid (S275JO): 10 x 25 mm
Flatsteel solid (S275JO): 25 x 20 (stehend), 25 x 16 (stehend) mm
Max. bending radius: 180 mm
Min. bending radius: 36 mm
Min. tube Ø: 10 mm
Max. bending speed: 2 r/min
Motor: 0.9 kW
Length: 245 mm
Width: 300 mm
Height: 320 mm
Weight: 23 kg

Bending length: 3100 mm
Sheet thickness (420 N/mm²): 3.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Length: 4300 mm
Width: 1770 mm
Height: 1890 mm
Weight: 4520 kg

Bending length: 3100 mm
Sheet thickness (420 N/mm²): 2.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Length: 4300 mm
Width: 1770 mm
Height: 1890 mm
Weight: 4000 kg

Bending length: 2540 mm
Sheet thickness (420 N/mm²): 6.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Length: 3900 mm
Width: 1750 mm
Height: 2050 mm
Weight: 6200 kg

Bending length: 2540 mm
Sheet thickness (420 N/mm²): 4.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Length: 3900 mm
Width: 1700 mm
Height: 1900 mm
Weight: 5100 kg

Bending length: 2540 mm
Sheet thickness (420 N/mm²): 3.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Motor: 3.7 kW
Length: 3850 mm
Width: 1700 mm
Height: 1860 mm
Weight: 3900 kg

Bending length: 2540 mm
Sheet thickness (420 N/mm²): 2.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Length: 3850 mm
Width: 1700 mm
Height: 1800 mm
Weight: 3400 kg

Flexion modulus: 4 cm³
Standard steel tube: 42 x 3 mm
Furniture tube: 48 x 1,5 mm
FE35 (for hydraulic tubes): 42 x 4 mm
Stainless steel AISI304-318: 42 x 3 mm
Stainless steel AISI308 (food industry): 42 x 2,5 mm
Brass soft: 50 x 3 mm
Hard copper and aluminium: 54 x 2 mm
Soft copper: 60 x 2 mm
Conduit tube (TAZ): 60 x 2 mm
Mepla, Gebereit and similar: 50 x 4 mm
Roundbar solid (S275JO): 30 mm
Flatsteel solid (S275JO): 40x20 (liegend), 40x12 (stehend) mm
Max. bending radius: 260 mm
Min. bending radius: 10 mm
Max. bending speed: 4 r/min
Motor: 1.1 kW
Length: 400 mm
Width: 570 mm
Height: 1000 mm
Weight: 80 kg

Theisen en Bonitz Sprint B312 VP ( 2008)

Year: 2008
- 12 stations
– format: min. 7x10cm, max. 35x50cm
– paper weight: 18-800g/qm

with Theisen en Bonitz 304 QSM

Theisen & Bonitz 304 QSM

Stitching and folding device:
– Motorized format setting
– 2 Hohner stitching heads
– Friction free Knife Fold (cloth system)
– Automatic layer thickness adjustment
– Front cutting device for cutting to 4 cm,
sections greater than 1.5 cm
– Head and foot trimming each from 3 to 20 mm at about 80 pages,
80 g / sqm.
– Power: 400 V, 50 Hz

Distance spindle - table: 600 mm
Table: 1.000 x 400 mm
Grinding lenght: 1015 mm
Magnetic table: 1.000 x 400 mm
Table movement hydraulic: 1100 mm
Table speed: 5 - 25 m/min
Cross feed: 0 - 3000 m/min
Max. cross feed: 450 mm
Automatic vertical feed: 440 mm
Vertical feed: 0 - 3000 mm/min
Vertical feed incremental: 0.001 mm
Spindle revs: 500 - 1800 rpm
Spindle motor: 11 kW
Hydraulic motor: 2.2 kW
Cross feed motor: 1.1 kW
Feed motor grinding wheel: 1.1 kW
Max. workpiece weight on magnetic table: 250 kg
Max. workpiece weight on t-slot table: 470 kg
Grinding wheel dimensions: 355 x 50 x 127 mm
Length: 4450 mm
Width: 2655 mm
Height: 2080 mm
Weight: 4200 kg

Laser power: 3 kW
Manual table / shuttle table: -
Max. thickness - mild steel: 10 mm
Max tube Ø: 160 mm
Min. tube Ø: 10 mm
Max. square Tube Dimension: 120 x 120 mm
Max. rectangular tube dimension: 150 x 100 mm
Max. tube lenght: 6000 mm
Max. tube weight: 40 kg/m
Positioning accuracy: +/- 0,2 mm
Repeat accuracy: +/- 0,05 mm
Tube types: round, square, rectangular, elliptic I, C, L
Max speed x-axes: 40 m/min
Max speed y-axes: 94 m/min
Max. speed Z axis: 30 m/min
Max. speed A-axix: 600 °/s

Blade length: 250 mm
Sheet thickness (420 N/mm²): 6 mm
Sheet thickness (600 N/mm²): 3 mm
Strokes: 25 1/min
Angle: 90 °
Motor: 4 kW
Length: 950 mm
Width: 780 mm
Height: 1115 mm
Weight: 585 kg

Blade length: 200 mm
Sheet thickness (420 N/mm²): 4 - 6 mm
Sheet thickness (600 N/mm²): 2 - 3 mm
Strokes: 30 1/min
Angle: 30 - 140 °
Motor: 4 kW
Length: 900 mm
Width: 1150 mm
Height: 1240 mm
Weight: 1150 kg

pressing capacity: 150 to
Cylinder fix or moveable: fix
Stroke: 300 mm
Daylight: 610 mm
Distance between columns: 1520 mm
Rapid speed: 9 mm/s
Working speed: 5 mm/s
Retraction speed: 10 mm/s
Table: 600x1520 mm
Hole in table: 100 mm
Hole distance: 190 mm
Length: 2630 mm
Width: 1000 mm
Height: 2470 mm
Weight: 3200 kg
