pressing capacity: 100 to
Cylinder fix or moveable: fix
Daylight: 900 mm
Distance between columns: 1050 mm
Length: 1900 mm
Width: 850 mm
Height: 2250 (PSS: 2400) mm

pressing capacity: 70 to
Cylinder fix or moveable: horizontal moveable
Daylight: 900 mm
Distance between columns: 900 mm
Length: 1700 mm
Width: 700 mm
Height: 2100 (PSS: 2300) mm

pressing capacity: 70 to
Cylinder fix or moveable: fix
Daylight: 900 mm
Distance between columns: 900 mm
Length: 1700 mm
Width: 700 mm
Height: 2100 (PSS: 2300) mm

pressing capacity: 20 to
Cylinder fix or moveable: fix
Daylight: 825 mm
Distance between columns: 520 mm
Length: 1150 mm
Width: 500 mm
Height: 1800 (PSS: 1950) mm

ECKOLD KF 653 C - Kraftformer

-Ausladung - horizontal ca. 600mm
-Ausladung - vertikal ca. 480mm
-Arbeitshub 8mm
-Stößelverstellung ca. 80mm
-Fußschalter
-1xWerkzeug
-Umformbare Blechdicken:
-Stahl (400 N/mm2) max. 6mm
-Aluminium (250 N/mm2) 8mm
-Edelstahl ( 600 N/mm2) 4mm

Abmaße:
LxBxH 1,6x0,7x1,9 Meter / Gewicht 1770Kg

ELB - SWN 5 VA II Flachschleifmaschine

-Schleifbereich X/Y/Z 525x375x255mm
-Magnetplatte 700x300mm
-Tischaufspannfläche 900x250mm
-Tischlängshub 10-625mm
-Tischbelastung max. 280Kg
-Tischvorschub 1-30 m/min
-Pendelschleifen 3-30 m/min
-Abstand - Tisch bis Spindelmitte 525mm
-Vertikal Vorschubgeschwindigkeit 2-180 mm/min
-Zustellgröße - regelbar 0,001-2mm
-Schleifscheibendrehzahl 3000 U/min
-Kühlmitteleinrichtung
-Maschinenfüße
-Dokumentation
-KOMPLETTE TECHNISCHE DATEN SIEHE FOTOS

Abmaße:
LxBxH 2,7x2,2x2 Meter / Gewicht 3500Kg

E.Büker - Typ N76 Endenbearbeitungsmaschine / Anfasmaschine

-Arbeitsbereich 6 - 76mm
-Drehzahl 10-1800 U/min
-Leistung 0,75 KW
-Unterbau
-Not-Aus

Abmaße:
LxBxH 0,7x0,5x1,4 Meter / Gewicht 250Kg

Laser power: 3 kW
Manual table / shuttle table: Manual table
Max. thickness - mild steel: 16 mm
Max. thickness - stainless steel: 8 mm
Max. thickness - aluminium: 8 mm
Max. Application Range - Copper: 5 mm
Max. Application Range - Brass: 8 mm
Cutting area: 3.048 x 1.530 mm
X-axis: 3048 mm
Y-axis: 1530 mm
Z-Axis: 125 mm
Max. Sheet size: 3.048 x 1.524 mm
Max. sheet weight: 127 kg/m²
Max speed x-axes: 90 m/min
Max speed y-axes: 90 m/min
Max. speed simultaneous: 127 m/min
Max. acceleration: 14 m/s²
Positioning accuracy: +/- 0,05 mm
Repeat accuracy: +/- 0,05 mm
Total space length U: 5310 mm
Total space width G: 2810 mm
Height: 1860 mm
Weight: 6600 kg

Shaft diameter: 60
Rolls diameter: 177 mm
Driven rolls: 3
Motor power: 3.7 kW
Speed: 6 m/min
Flat steel vertical position (section / min. diameter): 70x10 mm / 600 mm, 30x10 mm / 250 mm
Flat steel horizontal position (section / min. diameter): 90x25 mm / 500 mm, 50x5 mm / 250 mm
Square bar (section / min. diameter): 40x40 mm / 500 mm, 20x20 mm / 300 mm
Round bar (section / min. diameter): Ø. 40 mm / 500 mm, Ø 20 mm / 300 mm
Tube (section / min. diameter): Ø 60x2 mm / 600 mm, Ø 20x1 / 250 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 80x40x3 mm
Form tube square (section / min. diameter): 60x60x4 mm
Angle leg outside (Querschnitt / min. Durchmesser): 50x5 mm / 1.000 mm, 30x4 mm / 350 mm
Angle leg inside (section / min. diameter): 50x5 mm / 500 mm, 30x3 mm / 250 mm
Length: 1160 mm
Width: 1000 mm
Height: 1175 mm
Weight: 1194 kg

pressing capacity: 70 to
Cylinder fix or moveable: horizontal moveable
Stroke: 350 mm
Daylight: 900 mm
Distance between columns: 1050 mm
Working speed: max. 9 mm/s
Motor power: 2 kW
Horizontal movable cylinder: 650 mm
Length: 1950 mm
Width: 1000 mm
Height: 2250 mm
Weight: 1220 kg

Bending length: 2540 mm
Sheet thickness (420 N/mm²): 3.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Motor: 3.7 kW
Length: 3850 mm
Width: 1700 mm
Height: 1860 mm
Weight: 3900 kg

Bending length: 2540 mm
Sheet thickness (420 N/mm²): 2.5 mm
Antrieb: Hydraulic
Max. bending angle: 135 °
Length: 3850 mm
Width: 1700 mm
Height: 1800 mm
Weight: 3400 kg

Flexion modulus: 19 cm³
Standard steel tube: 38 x 1,5 mm
Furniture tube: 38 x 1,5 mm
FE35 (for hydraulic tubes): 35 x 3 mm
Stainless steel AISI304-318: 30 x 2 mm
Stainless steel AISI308 (food industry): 35 x 1,5 mm
Brass soft: 42 x 1,5 mm
Hard copper and aluminium: 42 x 1,5 mm
Soft copper: 50 x 2 mm
Conduit tube (TAZ): 50 x 2 mm
Mepla, Gebereit and similar: 50 x 4 mm
Roundbar solid (S275JO): 20 mm
Squarebar solid (S275JO): 10 x 25 mm
Flatsteel solid (S275JO): 25 x 20 (stehend), 25 x 16 (stehend) mm
Max. bending radius: 180 mm
Min. bending radius: 36 mm
Min. tube Ø: 10 mm
Max. bending speed: 2 r/min
Motor: 0.9 kW
Length: 245 mm
Width: 300 mm
Height: 320 mm
Weight: 23 kg

Drilling capacy mild steel: 18 mm
Taper: MK 2
Distance spindle - column: 240 mm
Revs: 30 - 3000 r.p.m.
Tapping capacity: M12
Quill travel: 100 mm
Distance spindle - table: 155 - 415 mm
Distance spindle-base: 155 - 550 mm
Table: 340 x 280 mm
Column diameter: 82 mm
Length: 355 mm
Width: 705 mm
Height: 1065 mm
Weight: 170 kg

Drilling capacy mild steel: 10 mm
Taper: B 16
Distance spindle - column: 180 mm
Revs: 250 - 3000 r.p.m.
Motor: 0,45 (230V) kW
Quill travel: 50 mm
Distance spindle - table: 105 - 245 mm
Table: 300 x 200 mm
Column diameter: 50 mm
Length: 400 mm
Width: 248 mm
Height: 460 mm
Weight: 30 kg

ang 470 PLC Ring Binder & Lever arch Assembly Line

High-performance automatic production line for ring binders
Brand: Hang
Year: 2007
Model: 470 PLC – FANUC Controlled

This fully automatic line is designed for efficient production of ring binders according to customer specifications. The machine is equipped with multiple processing stations and a Fanuc PLC control with touchscreen interface.

Main Components:

Sheet feeder (Saug-Anleger)
Creasing station
Gripping hole punching unit (Griffloch-Ösmaschine)
Double riveting station
Operator control panel (Fanuc QuickPanel View)
Mechanic feeding unit
Single riveting station
Folding station
Technical Specifications

PLC Control: FANUC with memory for up to 1000 programs and modem for remote support

Setup time: Approx. 2-3 minutes

Material Range:

Cover height: 120 – 400 mm
Cover width: 300 – 820 mm

Material thickness: Min. 1 mm – Max. 3.5 mm
Rivet spacing: 90 – 300 mm

Machine Condition

- In excellent working condition
-Touch panel with program counter, total counter and production statistics
- Fanuc QuickPanel View display
- Ready for immediate production
- Available for inspection in our warehouse

Production Counter Information (Machine Usage)

Day Counter: 250,895 cycles
Total Counter: 9,495,162 cycles
Product Counter: 1,336,482 units
Operating Time: 12,838 hours

Polar Stainless conveyor 2017, stainless elevator conveyor, elevates from 250mm to 900mm, belt width 300mm, overall length 4000mm, with 50Kg hopper and side guides,

GEA Niro NS2006P piston homogeniser, Serial: 12590, 2016, Stainless, Max Press. (Mpa) 25, rated flow rate 150 dm3/h, 3Ph

GEA Niro NS2006P piston homogeniser, Serial: 6233, 2005, Stainless, Max Press. (Mpa) 25, rated flow rate 150 dm3/h, 3Ph

Blechbreite: 1250 mm
Blechstärke: 2 mm
Anbiegung: .
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: t
Raumbedarf ca.: m

Druck: 100 t
Abkantlänge: 3000 mm
Ständerweite: 2550 mm
Hub: 150 mm
Gesamtleistungsbedarf: kW
Betriebsstunden: . h
Maschinengewicht ca.: 8,3 t
Raumbedarf ca.: m

Bohrleistung in Stahl (Durchmesser): . mm
Ausladung: 1250 mm
Werkstückhöhe - max.: . mm
Bohrleistung in Guss: 60 mm
Bohrleistung in St 60 - Aufbohren: . mm
Gewindeschneiden: .
Pinolendurchmesser: . mm
Spindelaufnahme MK: MT5
Drehzahl: 28-2.500 U/min
Vorschub: mm/U
Aufspannfläche: mm
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: t

Drilling capacy mild steel: 18 mm
Taper: MK 2
Distance spindle - column: 240 mm
Revs: 30 - 3000 r.p.m.
Tapping capacity: M12
Feeds: manual mm/r
Column diameter: 82 mm
Distance spindle - table: 180 - 870 mm
Table: 340 x 280 mm
Quill travel: 100 mm
Length: 705 mm
Width: 355 mm
Height: 1825 mm
Weight: 195 kg

Spindeldurchmesser: 250 mm
x-Weg: 12000 mm
y-Weg: 5850 mm
z-Weg: 1600 mm
w-Achse: 2000 mm
Steuerung: Siemens
Typ: 840 D Powerline
Drehzahl: 875 U/min
Traghülsenabmessung: 540x560 mm
Kühlmitteleinrichtung: 1800 l
Gesamtleistungsbedarf: kW
Maschinengewicht ca.: 130 t

Drilling capacy mild steel: 30 mm
Taper: MK 3
Distance spindle - column: 300 mm
Revs: 0 - 4000 r.p.m.
Motor: 3 kW
Tapping capacity: M30x3,5
Feeds: 0,10 / 0,16 / 0,25 mm/r
Column diameter: 125 mm
Distance spindle - table: 150 - 700 mm
Table: 590 x 450 mm
Quill travel: 125 mm
Length: 900 mm
Width: 610 mm
Height: 1980 mm
Weight: 385 kg

Saw frame: Pivot frame
Band dimensions: 3120 x 27 x 0,9 mm
Band speed continous: 15 - 101 m/min
Cutting capacity 0° round: 280 mm
Cutting capacity 0° square: 240 mm
Cutting capacity 0° flat: 310 x 240 mm
Cutting capacity 45°: round 230 mm, square 230 mm, rectangular 230x230 mm
Cutting capacity 60°: round 140 mm, square 140 mm, rectangular 140x140 mm
Cutting capacity - 45°: round 200 mm, square 170 mm, rectangular 220x100 mm
Min. rest piece length: 240 mm
Working height: 835 mm
Hydraulic motor: 0.37 kW
Motor: 1 kW
Coolant pump motor: 0.12 kW
Torque feeding carriage motor: 1.95 Nm
Torque motor for automatic bow rotation: 1.95 Nm
Length: 5150 mm
Width: 3200 mm
Height: 1950 mm
Transport dimensions: 5000 x 2200 x 1900 mm
Weight: 2150 kg

Ref. no.: 18565
Hersteller: DEMAG
Year of construction: 2005

Clamping unit
Clamping force: 150 ton
Opening stroke: 500 mm
Distance between tie bars: 500 x 500 mm
Mould height min.: 250 mm
Opening width: 750 mm
Platen size (h x v): 750 x 750 mm

Injection unit
Screw diameter: 45 mm
Injection volume: 323 cm³
Shot weight: 290 g
Injection pressure: 1973 bar

Measurements and weight
Dimensions: 5.45 x 1.63 x 2.1 m
Machine weight: 7500 kg

Robot
Producer: Wittmann
Type: W721-0231
Year: 2005

Saw frame: Double column
Band dimensions: 5400x41x1,3 mm
Band speed continous: 20-100 m/min
Cutting capacity 0° round: 450 mm
Cutting capacity 0° square: 425 mm
Cutting capacity 0° flat: 560x425 mm
Cutting capacity 45°: rund 430 mm, quadrat 425 mm, rechteck 430 x 425 mm
Cutting capacity 60°: rund 320 mm, quadrat 290 mm, rechteck 425 x 260 mm
Working height: 690 mm
Hydraulic motor: 0.55 kW
Motor: 4 kW
Coolant pump motor: 0.12 kW
Length: 3090 mm
Width: 1200 mm
Height: 1940 mm
Weight: 1630 kg

Saw frame: Double column
Band dimensions: 6300x41x1,3 mm
Band speed continous: 15 - 120 m/min
Cutting capacity 0° round: 440 mm
Cutting capacity 0° square: 440 mm
Cutting capacity 0° flat: 640 x 440 mm
Cutting capacity 45°: round 440 mm, rectangular 400 x 440 mm, square 400 mm
Cutting capacity 60°: round 250 mm, rectangular 250 x 440 mm, square 250mm
Cutting capacity - 45°: round 390 mm, rectangular 390 x 440 mm, square 390 mm
Working height: 860 mm
Hydraulic motor: 1.1 kW
Motor: 4 kW
Coolant pump motor: 0.12 kW
Length: 3150 mm
Width: 1850 mm
Height: 2115 mm
Weight: 2050 kg

Saw frame: Double column
Band dimensions: 5000x34x1,1 mm
Band speed continous: 20-100 m/min
Cutting capacity 0° round: 360 mm
Cutting capacity 0° square: 360 mm
Cutting capacity 0° flat: 640x360 mm
Cutting capacity 45°: rechteck 390 x 360 mm
Cutting capacity 60°: rechteck 250 x 360 mm
Cutting capacity - 45°: rechteck 390 x 360 mm
Working height: 800 mm
Hydraulic motor: 1.1 kW
Motor: 3 kW
Coolant pump motor: 0.12 kW
Length: 3000 mm
Width: 1850 mm
Height: 2000 mm
Weight: 1950 kg

Saw frame: Pivot frame
Band dimensions: 4160x34x1,1 mm
Band speed continous: 20-100 m/min
Cutting capacity 0° round: 320 mm
Cutting capacity 0° square: 320 mm
Cutting capacity 0° flat: 610x320 mm
Cutting capacity 30°: rund 260 mm, quadrat 225 mm, rechteck 280 x 200 mm
Cutting capacity 45°: rund 320 mm, quadrat 320 mm, rechteck 355 x 320 mm
Cutting capacity 60°: rund 320 mm, quadrat 320 mm, rechteck 510 x 320 mm
Working height: 740 mm
Hydraulic motor: 0.37 kW
Motor: 2.2 kW
Coolant pump motor: 0.12 kW
Cutting capacity 75°: rund 320 mm, quadrat 320 mm, rechteck 580 x 320 mm
Length: 2100 mm
Width: 1200 mm
Height: 1350 mm
Weight: 1150 kg

Punching power: 35 ton
Throat depth: 60 mm
Max. hole diameter: 27 mm
Max. oblong hole: 25x18 mm
Punching time: 5 s
Max. sheet thickness - mild steel: 13 mm
Working pressure: 700 bar
Length: 379 mm
Width: 148 mm
Height: 335 mm
Weight: 20 kg

Coil weight: 2500 kg
Coil outer diameter: 1300 mm
Min. coil inner diameter: 450 mm
Max. Coil inner diameter: 550
Max. coil width: 600 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm

Coil weight: 2500 kg
Coil outer diameter: 1300 mm
Min. coil inner diameter: 450 - 550 mm
Max. coil width: 400 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm

Coil weight: 1250 kg
Coil outer diameter: 1300 mm
Min. coil inner diameter: 450 - 550 mm
Max. coil width: 400 mm
Min. Coil width: 50
Min. coil width for version with pneumatic downholder: 80 mm

Bending length: 350 - 2800 mm
Max. sheet length: 3050 mm
Max. sheet width: 1524 mm
Min. bendable width: 150 mm
Max. bending height: 254 mm
Max. bending depth: 50 mm
Max. sheet rotation area: 3300 mm
Bending force: 500 to
Pressure force: 1000 to
Sheet thickness (420 N/mm²): 3.2 mm
Sheet thickness (600 N/mm²): 2.2 mm
Sheet thickness (260 N/mm²): 4 mm
Min. sheet thickness - mild steel: 0.5 mm
Max. bending angle: 135 °

Suitable for plates: 1
Max. bevel width: 35 mm
Bevel angle: 60 °
Spindle speed (load-free): 2780 rpm
Plate thickness: 35 mm
Feed speed: 250 - 500 mm/min
Motor: 1.6 kW
Weight: 54 kg

Working width: 1300
Sheet thickness range - mild steel: 150 mm
Brush diameter: 150 mm
Vacuum area: 250x350 mm
Table height: 945 mm
Motor: 0.75 kW
Length: 1400 mm
Width: 1000 mm
Height: 1450 mm
Weight: 300 kg

Cutting length: 1530 mm
Max. thickness - mild steel: 16 mm
Max. thickness - stainless steel: 12 mm
Strokes: 7 1/min
Cutting angle: 3 °
Number of downholders: 8 pcs.
Back gauge: 500 mm
Motor power: 22.5 kW
Oiltank: 250 l
Table height: 950 mm
Length: 2350 mm
Width: 1400 mm
Height: 2000 mm
Weight: 5200 kg

Cutting length: 1280 mm
Max. thickness - mild steel: 16 mm
Max. thickness - stainless steel: 12 mm
Strokes: 8 1/min
Cutting angle: 3 °
Number of downholders: 7 pcs.
Back gauge: 500 mm
Motor power: 22.5 kW
Oiltank: 250 l
Table height: 950 mm
Length: 2100 mm
Width: 1400 mm
Height: 2000 mm
Weight: 5000 kg

Cutting length: 1280 mm
Max. thickness - mild steel: 12 mm
Max. thickness - stainless steel: 9 mm
Strokes: 9 1/min
Cutting angle: 3 °
Number of downholders: 7 pcs.
Back gauge: 500 mm
Motor power: 15 kW
Oiltank: 180 l
Table height: 950 mm
Length: 1950 mm
Width: 1200 mm
Height: 1800 mm
Weight: 3200 kg

Cutting length: 6080 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Gap in side frame: 350 mm
Strokes: 10 1/min
Cutting angle: 0,5 - 2 °
Number of downholders: 29 pcs.
Pressure of downholder: 20 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 22 kW
Oiltank: 200 l
Support arms: 5 pcs.
Table height: 900 mm
Table width: 630 mm
Table length: 6370 mm
Length: 7300 mm
Width: 2150 mm
Total width with support arm und protection fence: 3400 mm
Height: 2750 mm
Weight: 25500 kg

Cutting length: 3080 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Gap in side frame: 350 mm
Strokes: 20 1/min
Cutting angle: 0,5 - 2 °
Number of downholders: 16 pcs.
Pressure of downholder: 20 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 11 kW
Oiltank: 125 l
Support arms: 3 pcs.
Table height: 820 mm
Table width: 494 mm
Table length: 3280 mm
Length: 4100 mm
Width: 2050 mm
Total width with support arm und protection fence: 3650 mm
Height: 1950 mm
Weight: 7980 kg

Swing over bed: 500 mm
Distance between centers: 1500 mm
Centre height: 250 mm
Spindle bore: 80 mm
swing over cross slide: 300 mm
Width of bed: 400 mm
Spindle nose / DIN55027: 8
Spindle taper: 80 M
Spindle speed steps: 21
Spindle revs: Array rpm
Number of feeds: 120
Longitudinal feed range: 0.04 - 12 mm/r
Cross feed range: 0.02 - 6 mm/r
Number of threads: 64
Metric thread range: 0.5 - 120 mm
Inch thread range: Array Tpi
Module thread range: 0.125 - 30
DP thread range: Array
Cross slide travel: 315 mm
Top slide travel: 130 mm
Tailstock quill diameter: 90 mm
Tailstock quill taper: 5 MK
Tailstock travel: 230 mm
Motor power: 7 kW
Length: 3100 mm
Width: 1250 mm
Height: 1400 mm
Weight: 2820 kg

pressing capacity: 400 to
Bending length: 4050 mm
Axes: Y1 / Y2 / X Achse
Stroke: 365 mm
Inside distance between side frames: 3400 mm
Gap in side frame: 510 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 160 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 140
Back gauge speed X-axis: 500
Back gauge speed R-axis: 350 mm/s
Back gauge travel R-axis: 250 mm
Table height: 1050 mm
Table width: 154 mm
Oiltank: 250 l
Motor power: 37 kW
Length: 5750 mm
Width: 2110 mm
Height: 3640 mm
Weight: 27760 kg

6V Openings: 8/11/12/16/24/36 mm
Length: 2500 mm
Width: 70 mm
Height: 70 mm

Punching power: 30 ton
Working area: 3000x1500 mm
X-axis movement (+repositioning): 3000 mm
Y-axis movement: 1500 mm
speed of X-axis: 70 m/Min
speed of Y-axis: 60 m/min
speed combined X+Y: 120 m/min
Stroke: 40 mm
Max. strokes (in 1 mm steps, 1 mm thickness): 1200 1/min
Max. strokes (in 25 mm steps, 1 mm thickness): 325 1/min
Max. strokes at marking: 2800 1/min
Max. cutting thickness with fix tool station steel: 6 mm
max. cutting thickness with fix tool station stainless steel: 3 mm
Max. cutting thickness with index tool station steel: 3 mm
Max. cutting thickness with index tool station stainless steel: 1.5 mm
Number of stations: 28
Positioning accuracy: 0.1 mm
Repeat accuracy: 0.05 mm
Turret rotation speed: 22 rpm
Autoindex-rotation speed: 150 rpm
Max. work piece weight: 200 kg
Table height: 940 mm
Air pressure: 6 bar
Max. punching diameter (D-station): 88.9 mm
Motor power: 7.5 kW
Oiltank: 180 l
Length without light barrier: 6650 mm
Length with light barrier: 7650 mm
Width without light barrier: 6300 mm
Width with light barrier: 8300 mm
Height: 2310 mm
Weight: 18250 kg

Punching power: 30 ton
Working area: 2500x1250 mm
X-axis movement (+repositioning): 2500 mm
Y-axis movement: 1250 mm
speed of X-axis: 116 m/Min
speed of Y-axis: 80 m/min
speed combined X+Y: 140 m/min
Stroke: 40 mm
Max. strokes (in 1 mm steps, 1 mm thickness): 1200 1/min
Max. strokes (in 25 mm steps, 1 mm thickness): 425 1/min
Max. strokes at marking: 3200 1/min
Max. cutting thickness with fix tool station steel: 6 mm
max. cutting thickness with fix tool station stainless steel: 3 mm
Max. cutting thickness with index tool station steel: 3 mm
Max. cutting thickness with index tool station stainless steel: 1.5 mm
Number of stations: 27
Turret rotation speed: 22 rpm
Autoindex-rotation speed: 150 rpm
Max. work piece weight: 120 kg
Table height: 940 mm
Air pressure: 6 bar
Max. punching diameter (D-station): 88.9 mm
Motor power: 15 kW
Length without light barrier: 5750 mm
Length with light barrier: 6800 mm
Width without light barrier: 5360 mm
Width with light barrier: 7360 mm
Height: 2310 mm
Weight: 12960 kg

Punching power: 20 ton
Working area: 2000x1250 mm
X-axis movement (+repositioning): 2000 mm
Y-axis movement: 1250 mm
speed of X-axis: 90 m/Min
speed of Y-axis: 70 m/min
speed combined X+Y: 114 m/min
Max. strokes (in 1 mm steps, 1 mm thickness): 1100 1/min
Max. strokes (in 25 mm steps, 1 mm thickness): 375 1/min
Max. strokes at marking: 1200 1/min
Max. cutting thickness with fix tool station steel: 6 mm
max. cutting thickness with fix tool station stainless steel: 3 mm
Max. cutting thickness with index tool station steel: 3 mm
Max. cutting thickness with index tool station stainless steel: 1.5 mm
Number of stations: 27
Turret rotation speed: 30 rpm
Autoindex-rotation speed: 150 rpm
Max. work piece weight: 100 kg
Table height: 940 mm
Air pressure: 6 bar
Max. punching diameter (D-station): 88.9 mm
Motor power: 7.5 kW
Length without light barrier: 5600 mm
Length with light barrier: 6600 mm
Width without light barrier: 4200 mm
Width with light barrier: 6200 mm
Height: 2310 mm
Weight: 11000 kg

Ref. no.: 18591
Hersteller: ARBURG
Year of construction: 2005

Clamping unit
Clamping force: 160 ton
Opening stroke: 450 mm
Distance between tie bars: 520 x 520 mm
Mould height min.: 250 mm
Mould height max.: 550 mm
Opening width: 700 mm
Platen size (h x v): 695 x 695 mm

Injection unit
Screw diameter: 45 mm
Injection volume: 254 cm³
Shot weight: 232 g
Injection pressure: 1580 bar

Measurements and weight
Machine weight: 7100 kg
Dimensions LxWxH part 1: 5,1 x 1,7 x 2,3 m
