pressing capacity: 400 to
Bending length: 6050 mm
Axes: Y1 / Y2 / X und R Achse
Stroke: 365 mm
Inside distance between side frames: 5100 mm
Gap in side frame: 510 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 150 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 150
Back gauge travel X-axis: 750 mm
Oiltank: 160 l
Motor power: 2x11 kW
Length: 7500 mm
Width: 2110 mm
Height: 3810 mm
Weight: 34600 kg

pressing capacity: 320 to
Bending length: 6050 mm
Axes: Y1 / Y2 / X und R Achse
Stroke: 365 mm
Inside distance between side frames: 5100 mm
Gap in side frame: 450 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 160 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 160
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge travel R-axis: 250 mm
Table height: 1100 mm
Table width: 154 mm
Oiltank: 160 l
Motor power: 2 x 11 kW
Length: 7500 mm
Width: 1910 mm
Height: 3350 mm
Weight: 29000 kg

pressing capacity: 400 to
Bending length: 4050 mm
Axes: Y1 / Y2 / X und R Achse
Stroke: 365 mm
Inside distance between side frames: 3400 mm
Gap in side frame: 410 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 160 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 160
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 154 mm
Motor power: 2 x 11 kW
Length: 5750 mm
Width: 2110 mm
Height: 3450 mm
Weight: 27780 kg

pressing capacity: 60 to
Bending length: 2050 mm
Axes: 4 (Y1, Y2, X, R)
Stroke: 265 mm
Inside distance between side frames: 1700 mm
Gap in side frame: 450 mm
Daylight: 530 mm
Power concept: hydraulic
rapid speed Y-axis: 200 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 110
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge speed R-axis: 350 mm/s
Back gauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 104 mm
Oiltank: 100 l
Motor: 7.5 kW
Back gauge: 650 mm
Length: 3200 mm
Width: 1550 mm
Height: 2850 mm
Weight: 5600 kg

Bending length: 2040 mm
Sheet thickness (420 N/mm²): 0.8 mm
Max. bending angle: 70 °
Length: 2400 mm
Width: 750 mm
Height: 850 mm
Weight: 290 kg

Cutting length: 2500 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Strokes: 15 1/min
Cutting angle: 1°50’ °
Number of downholders: 12 pcs.
Pressure of downholder: 8.5 to
Back gauge: 750 mm
Back gauge speed: 120 mm/s
Motor power: 11 kW
Oiltank: 150 l
Table height: 880 mm
Table width: 500 mm
Stroke: 125 mm
Length: 3300 mm
Width: 2615 mm
Height: 1650 mm
Weight: 4940 kg

Max. thickness - mild steel: 5 mm
Throat depth: 1200 mm
Motor: 2,2+0,75 kW
Speed: 4 m/min
min / max diameter: 250 / 2000 mm
gap on blade side: 300 mm
Length: 3000 mm
Width: 750 mm
Height: 1400 mm
Weight: 1350 kg

Blade length: 197 mm
Sheet thickness (420 N/mm²): 4 mm
Sheet thickness (600 N/mm²): 2 mm
Strokes: 20 1/min
Angle: 90 °
Motor: 4 kW
Length: 890 mm
Width: 780 mm
Height: 1115 mm
Weight: 550 kg

Sheet Thickness - mild steel: 0.4 - 4 mm
Max. sheet width: 100 mm
Max. cross-section: 400 mm
Feed roll diameter: 80 mm
Motor torque: 10 Nm

Max. sheet thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Max. flanging radius: 70 mm
Max. blank diameter: 4000 mm
Min. blank diameter: 550 mm
Motor: 8.75 kW
Length: 4250 mm
Width: 720 mm
Height: 2000 mm
Weight: 2015 kg

Punching power: 30 ton
Working area: 1250+N x 1000 mm
X-axis movement (+repositioning): 1250 mm
Y-axis movement: 1000 mm
speed of X-axis: 40 m/Min
speed of Y-axis: 30 m/min
speed combined X+Y: 50 m/min
Stroke: 30 mm
Max. strokes (in 1 mm steps, 1 mm thickness): 730 1/min
Max. strokes (in 25 mm steps, 1 mm thickness): 300 1/min
Table height: 980 mm
Motor power: 4 kW
Oiltank: 115 l
Height: 4000 mm
Width without light barrier: 2800 mm
Length without light barrier: 2800 mm
Weight: 4800 kg

pressing capacity: 135 to
Bending length: 3050 mm
Axes: 4
Stroke: 320 mm
Inside distance between side frames: 3340 mm
Daylight: 500 mm
Power concept: servomotorized belt drive
rapid speed Y-axis: 100 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 100
Back gauge travel X-axis: 650 mm
Back gauge travel R-axis: 250 mm
Length: 4200 mm
Width: 2200 mm
Height: 2550 mm
Weight: 7300 kg

pressing capacity: 80 to
Bending length: 2550 mm
Axes: 4
Stroke: 320 mm
Inside distance between side frames: 2840 mm
Daylight: 500 mm
Power concept: servomotorized belt drive
rapid speed Y-axis: 105 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 105
Back gauge travel X-axis: 650 mm
Back gauge travel R-axis: 250 mm
Length: 3700 mm
Width: 2200 mm
Height: 2550 mm
Weight: 6400 kg

pressing capacity: 120 to
Bending length: 3100 mm
Stroke: 160 mm
Inside distance between side frames: 2550 mm
Gap in side frame: 240 mm
rapid speed Y-axis: 100 mm/s
Working speed Y-axis: 10
Table width: 230 mm
Motor: 11 kW
Back gauge: 600 mm
Retraction speed: 77 mm/s
Length: 3300 mm
Width: 2150 mm
Height: 2600 mm
Weight: 7500 kg

pressing capacity: 100 to
Stroke: 300 mm
Ram: 600 x 900 mm
Table: 700x1100 mm
Daylight: 550 mm
Rapid speed: 100 mm/s
Working speed: 8 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Length: 2100 mm
Width: 1750 mm
Height: 3050 mm
Weight: 6500 kg

pressing capacity: 60 to
Stroke: 250 mm
Ram: 550 x 850 mm
Table: 600x1000 mm
Daylight: 500 mm
Rapid speed: 100 mm/s
Working speed: 10 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Length: 1950 mm
Width: 1700 mm
Height: 2750 mm
Weight: 5300 kg

pressing capacity: 30 to
Stroke: 200 mm
Ram: 500х800 mm
Table: 500х800 mm
Daylight: 450 mm
Rapid speed: 100 mm/s
Working speed: 18 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Length: 1950 mm
Width: 1750 mm
Height: 2650 mm
Weight: 4700 kg

pressing capacity: 60 to
Stroke: 350 mm
Ram: 550х850 mm
Table: 600х1000 mm
Daylight: 600 mm
Rapid speed: 100 mm/s
Working speed: 10 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Working pressure: 170 bar
Die cushion pressing force: 24 to
Die cushion stroke: 150 mm
Table Drill Ø: 100 mm
Draw cushion working pressure: 156 bar
Draw cushion retraction speed: 65 mm/sec.
Draw cushion surface: 300х300 mm
Length: 1950 mm
Width: 1750 mm
Height: 2900 mm
Weight: 5350 kg

pressing capacity: 30 to
Stroke: 300 mm
Ram: 500х800 mm
Table: 600х900 mm
Daylight: 550 mm
Rapid speed: 100 mm/s
Working speed: 18 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Working pressure: 160 bar
Die cushion pressing force: 12 to
Die cushion stroke: 150 mm
Table Drill Ø: 80 mm
Draw cushion working pressure: 130 bar
Draw cushion retraction speed: 100 mm/sec.
Draw cushion surface: 250х250 mm
Length: 1950 mm
Width: 1750 mm
Height: 2800 mm
Weight: 4850 kg

Bending length: 1020 mm
Sheet thickness (420 N/mm²): 1.25 mm
Max. bending angle: 135 °
Stroke of upper flange: 50 mm
Length: 1500 mm
Width: 700 mm
Height: 1250 mm
Weight: 200 kg

pressing capacity: 100 to
Stroke: 500 mm
Ram: 600 x 900 mm
Table: 700 x 1100 mm
Daylight: 750 mm
Throat depth: 320 mm
Rapid speed: 100 mm/s
Working speed: 8 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Working pressure: 240 bar
Die cushion pressing force: 30 to
Die cushion stroke: 200 mm
Table Drill Ø: 120 mm
Draw cushion working pressure: 170 bar
Draw cushion retraction speed: 52 mm/sec.
Draw cushion surface: 700 x 400 mm

pressing capacity: 150 to
Stroke: 500 mm
Ram: 950 x 650 mm
Table: 1200 x 750 mm
Daylight: 750 mm
Rapid speed: 100 mm/s
Working speed: 5 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Working pressure: 254 bar
Die cushion pressing force: 32 to
Die cushion stroke: 200 mm
Table Drill Ø: 120 mm
Draw cushion working pressure: 160 bar
Draw cushion retraction speed: 40 mm/sec.
Length: 2225 mm
Width: 1600 mm
Height: 3850 mm
Weight: 10000 kg

Cutting length: 3100 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Gap in side frame: 50 mm
Strokes: 15 1/min
Cutting angle: 1 °
Number of downholders: 16 pcs.
Pressure of downholder: 14 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 15 kW
Oiltank: 200 l
Support arms: 2 pcs.
Table height: 865 mm
Table width: 500 mm
Table length: 3515 mm
Length: 4110 mm
Width: 2200 mm
Total width with support arm und protection fence: 3700 mm
Height: 2100 mm
Weight: 7300 kg

Shaft diameter: 60
Rolls diameter: 177 mm
Driven rolls: 3
Motor power: 3.7 kW
Speed: 6 m/min
Flat steel vertical position (section / min. diameter): 70x10 mm / 600 mm, 30x10 mm / 250 mm
Flat steel horizontal position (section / min. diameter): 90x25 mm / 500 mm, 50x5 mm / 250 mm
Square bar (section / min. diameter): 40x40 mm / 500 mm, 20x20 mm / 300 mm
Round bar (section / min. diameter): Ø. 40 mm / 500 mm, Ø 20 mm / 300 mm
Tube (section / min. diameter): Ø 60x2 mm / 600 mm, Ø 20x1 / 250 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 80x40x3 mm
Form tube square (section / min. diameter): 60x60x4 mm
Angle leg outside (Querschnitt / min. Durchmesser): 50x5 mm / 1.000 mm, 30x4 mm / 350 mm
Angle leg inside (section / min. diameter): 50x5 mm / 500 mm, 30x3 mm / 250 mm
Length: 1160 mm
Width: 1000 mm
Height: 1175 mm
Weight: 1194 kg

pressing capacity: 120 to
Bending length: 3050 mm
Axes: 4 (Y1, Y2, X, R)
Stroke: 180 mm
Inside distance between side frames: 2550 mm
Gap in side frame: 250 mm
Daylight: 375 mm
Power concept: hydraulic
Back gauge travel X-axis: 620 (with optional R-axis: 500 mm) mm
Table height: 878 mm
Table width: 104 mm
Oiltank: 150 l
Motor power: 11 kW
Length: 3750 mm
Width: 1230 mm
Height: 2400 mm
Weight: 5900 kg

Cutting length: 1050 mm
Max. thickness - mild steel: 2 mm
Strokes: 150 1/min
Back gauge: 500 mm
Length: 1500 mm
Width: 1700 mm
Height: 1100 mm
Weight: 800 kg

pressing capacity: 30 to
Bending length: 1050 mm
Axes: 3 (Y1, Y2, X)
Stroke: 160 mm
Inside distance between side frames: 850 mm
Gap in side frame: 250 mm
Daylight: 390 mm
Power concept: hydraulic
Working speed Y-axis: 10
Retractionspeed Y-axis: 130
Back gauge travel X-axis: 400 mm
Back gauge speed X-axis: 250
Table height: 835 mm
Table width: 104 mm
Oiltank: 75 l
Motor power: 7.5 kW
Length: 2470 mm
Width: 1250 mm
Height: 2245 mm
Weight: 3250 kg

Cutting length: 3100 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Strokes: 14 1/min
Cutting angle: 1 °
Number of downholders: 14 pcs.
Pressure of downholder: 8.5 to
Back gauge: 750 mm
Back gauge speed: 120 mm/s
Motor power: 11 kW
Oiltank: 170 l
Table height: 880 mm
Table width: 500 mm
Length: 3750 mm
Width: 1950 mm
Total width with support arm und protection fence: 2770 mm
Height: 1650 mm
Weight: 5550 kg

Bending length: 2550 mm
Max. bending capacity - mild steel: 13
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 13 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm
Upper roll diameter: 260 mm
Lower roll diameter: 260 mm
Lateral roll diameter: 200 mm
Bending speed: 1,5-6 m/min
Motor power: 7.5 kW
Length: 4800 mm
Width: 1600 mm
Height: 1550 mm
Weight: 6800 kg

Bending length: 2050 mm
Max. bending capacity - mild steel: 4
Upper roll diameter: 140 mm
Motor power: 2.2 kW
Length: 3200 mm
Width: 750 mm
Height: 1000 mm
Weight: 1650 kg

pressing capacity: 150 to
Stroke: 500 mm
Table: 1.550 x 2.000 mm
Daylight: 800 mm
Rapid speed: 20 mm/s
Working speed: 3 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 1550 mm
Horizontal movable cylinder: 1000 mm
Hydraulicaly movable stand: 1300 mm
Length: 2350 mm
Width: 2000 mm
Height: 2500 mm
Weight: 4100 kg

pressing capacity: 150 to
Stroke: 500 mm
Table: 2.500 x 2.050 mm
Daylight: 800 mm
Rapid speed: 20 mm/s
Working speed: 3 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 2050 mm
Horizontal movable cylinder: 1400 mm
Hydraulicaly movable stand: 1600 mm
Length: 2900 mm
Width: 2500 mm
Height: 2500 mm
Weight: 5200 kg

pressing capacity: 200 to
Stroke: 500 mm
Table: 2.500 x 2.050 mm
Daylight: 800 mm
Rapid speed: 20 mm/s
Working speed: 2 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 2050 mm
Horizontal movable cylinder: 1450 mm
Hydraulicaly movable stand: 1600 mm
Length: 2950 mm
Width: 2500 mm
Height: 2600 mm
Weight: 6500 kg

pressing capacity: 200 to
Stroke: 500 mm
Table: 3.000 x 2.550 mm
Daylight: 800 mm
Rapid speed: 20 mm/s
Working speed: 2 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 2550 mm
Horizontal movable cylinder: 1900 mm
Hydraulicaly movable stand: 2000 mm
Length: 3550 mm
Width: 3000 mm
Height: 2600 mm
Weight: 8500 kg

pressing capacity: 300 to
Stroke: 500 mm
Table: 4.000 x 2.550 mm
Daylight: 700 mm
Rapid speed: 20 mm/s
Working speed: 2 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 2550 mm
Horizontal movable cylinder: 1.8 mm
Hydraulicaly movable stand: 2.8 mm
Length: 3550 mm
Width: 4000 mm
Height: 2600 mm
Weight: 15000 kg

pressing capacity: 300 to
Stroke: 500 mm
Table: 5.000 x 3.050 mm
Daylight: 700 mm
Rapid speed: 20 mm/s
Working speed: 2 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 3050 mm
Horizontal movable cylinder: 2.2 mm
Hydraulicaly movable stand: 3.6 mm
Length: 4000 mm
Width: 5000 mm
Height: 2600 mm
Weight: 18000 kg

pressing capacity: 500 to
Stroke: 500 mm
Table: 5.000 x 2.550 mm
Daylight: 700 mm
Rapid speed: 18 mm/s
Working speed: 3 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 2550 mm
Horizontal movable cylinder: 1.7 mm
Hydraulicaly movable stand: 3.6 mm
Length: 5000 mm
Width: 5000 mm
Height: 3000 mm
Weight: 32000 kg

pressing capacity: 600 to
Stroke: 500 mm
Table: 6.000 x 2.550 mm
Daylight: 700 mm
Rapid speed: 18 mm/s
Working speed: 3 mm/s
Cylinder fix or moveable: horizontal moveable
Distance between columns: 2550 mm
Horizontal movable cylinder: 2200 mm
Hydraulicaly movable stand: 4600 mm
Length: 5000 mm
Width: 6000 mm
Height: 3000 mm
Weight: 43000 kg

Bending length: 2050 mm
Max. bending capacity - mild steel: 13
Max. plate thickness with prebending - mild steel: 10 mm
Max. plate thickness without prebending at D=5x upper roll diam. - mild steel: 13 mm
Max. plate thickness without prebending at D=1,5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=5x upper roll diam. - mild steel: 10 mm
Max. plate thickness with prebending at D=1,5x upper roll diam. - mild steel: 8 mm
Upper roll diameter: 240 mm
Lower roll diameter: 240 mm
Lateral roll diameter: 190 mm
Working height: 820 mm
Motor power: 11 kW
Length: 3830 mm
Width: 1160 mm
Height: 1200 mm
Weight: 5000 kg

Flexion modulus: 10 cm³
Round tube: 64 x 3 mm
Standard steel tube: 64 x 3,3 mm
Gas tube: 2" x 40 mm
Stainless steel: 60 x 2 mm
Hard copper and aluminium: 64 x 4 mm
Square tube: 60 x 60 x 4 mm
Rect. tube easy way: 40 x 60 x 4 bzw. Ø 60 x 40 x 3 mm
Rect. tube hard way: 60 x 40 x 3 mm
Max. outer diameter: 64 mm
Max. bending radius: 200 mm
Min. bending radius: 20 mm
Max. bending angle: 210 °
Motor: 4.2 kW
Hydraulic oil capacity: 50 l
Length: 4000 mm
Width: 950 mm
Height: 1250 mm
Weight: 850 kg

Flexion modulus: 170 cm³
Standard steel tube: 150 x 9 mm
Gas tube: 6" x 7,11 mm
Furniture tube: 150 x 9 mm
FE35 (for hydraulic tubes): 168,3 x 8,5 mm
Stainless steel AISI304-318: 141,3 x 6,55 mm
Stainless steel AISI308 (food industry): 141,3 x 6,55 mm
Brass soft: 168,3 x 9 mm
Hard copper and aluminium: 168,3 x 9 mm
Soft copper: 168,3 x 9 mm
Conduit tube (TAZ): 141,3 x 8 mm
Mepla, Gebereit and similar: 150 x 6 mm
Roundbar solid (S275JO): 110 mm
Squarebar solid (S275JO): 90 x 90 mm
Flatsteel solid (S275JO): 120 x 60 mm
Square profile (S275JO): 140 x 70 x 12 bzw. 140 x 140 x 6 mm
T-profile (S275JO): 120 x 120 x 10 mm
U-profile (S275JO): 120 x 120 x 8 mm
Max. bending radius: 800 mm
Min. bending radius: 100 mm
Min. tube Ø: 10 mm
Max. bending speed: 1 r/min
Motor: 15 kW
Length: 1000 mm
Width: 1900 mm
Height: 1475 mm
Weight: 2700 kg

Flexion modulus: 80 cm³
Standard steel tube: 127 x 7,1 mm
Gas tube: 4" x 8,56 mm
Furniture tube: 127 x 7,1 mm
FE35 (for hydraulic tubes): 100 x 11 mm
Stainless steel AISI304-318: 114,3 x 5,6 mm
Stainless steel AISI308 (food industry): 114,3 x 5,6 mm
Brass soft: 139,7 x 8,8 mm
Hard copper and aluminium: 139,7 x 8,8 mm
Soft copper: 139,7 x 8,8 mm
Conduit tube (TAZ): 120 x 9 mm
Mepla, Gebereit and similar: 120 x 6.5 mm
Roundbar solid (S275JO): 90 mm
Squarebar solid (S275JO): 75 x 75 mm
Flatsteel solid (S275JO): 100 x 50 mm
Square profile (S275JO): 120 x 60 x 9 bzw. 90 x 90 x 10 mm
T-profile (S275JO): 100 x 100 x 10 mm
U-profile (S275JO): 100 x 100 x 10 mm
Max. bending radius: 700 mm
Min. bending radius: 36 mm
Min. tube Ø: 10 mm
Max. bending speed: 0 - 0,75 r/min
Motor: 3.5 kW
Length: 850 mm
Width: 1200 mm
Height: 850 mm
Weight: 720 kg

Flexion modulus: 43 cm³
Standard steel tube: 100 x 6 mm
Gas tube: 3" 1/2 x 5,74 mm
Furniture tube: 100 x 6 mm
FE35 (for hydraulic tubes): 100 x 7,5 mm
Stainless steel AISI304-318: 100 x 3,6 mm
Stainless steel AISI308 (food industry): 100 x 3,6 mm
Brass soft: 114.3 x 6,3 mm
Hard copper and aluminium: 114,3 x 6,3 mm
Soft copper: 114,3 x 6,3 mm
Conduit tube (TAZ): 100 x 6 mm
Mepla, Gebereit and similar: 100 x 5 mm
Roundbar solid (S275JO): 70 mm
Squarebar solid (S275JO): 60 x 60 mm
Flatsteel solid (S275JO): 80 x 40 mm
Square profile (S275JO): 100 x 60 x 4 bzw. 90 x 90 x 4 mm
T-profile (S275JO): 90 x 90 x 6 mm
U-profile (S275JO): 90 x 90 x 6 mm
Max. bending radius: 400 mm
Min. bending radius: 36 mm
Min. tube Ø: 10 mm
Max. bending speed: 0 - 1,3 r/min
Motor: 3.5 kW
Length: 500 mm
Width: 1200 mm
Height: 850 mm
Weight: 480 kg

Flexion modulus: 10.5 cm³
Standard steel tube: 60 x 3 mm
Gas tube: 2"Gas x 4 mm
Furniture tube: 60 x 4 mm
FE35 (for hydraulic tubes): 64 x 4 mm
Stainless steel AISI304-318: 64 x 3 mm
Stainless steel AISI308 (food industry): 60 x 4 mm
Brass soft: 60 x 4 mm
Hard copper and aluminium: 64 x 4 mm
Soft copper: 64 x 4 mm
Conduit tube (TAZ): 60 x 4 mm
Mepla, Gebereit and similar: 50 x 4 mm
Roundbar solid (S275JO): 35 mm
Squarebar solid (S275JO): 30 x 30 mm
Flatsteel solid (S275JO): 10 x 60 mm
Square profile (S275JO): 25 x 50 x 3 bzw. 50 x 50 x 3 mm
T-profile (S275JO): 50 x 50 x 6 mm
U-profile (S275JO): 40 x 20 x 6 mm
Max. bending radius: 300 mm
Min. bending radius: 10 mm
Min. tube Ø: 10 mm
Max. bending speed: 1,25 / 2,60 r/min
Motor: 1 kW
Length: 595 mm
Width: 363 mm
Height: 900 mm
Weight: 130 kg

Shaft diameter: 100
Rolls diameter: 315 mm
Driven rolls: 3
Motor power: 7.5 kW
Speed: 7 m/min
Flat steel vertical position (section / min. diameter): 100x20 mm / 800 mm, 30x10 mm / 400 mm
Flat steel horizontal position (section / min. diameter): 200x30 mm / 1.200 mm, 160x35 mm / 800 mm, 80x5 mm / 400 mm
Square bar (section / min. diameter): 60x60 mm / 750 mm, 15x15 mm / 400 mm
Round bar (section / min. diameter): Ø 75 mm / 800 mm, Ø 15 mm / 450 mm
Tube (section / min. diameter): Ø 125x2,5 mm / 1.400 mm, Ø 15x1 mm / 450 mm, Ø 4"x6,02 / 1.000 mm, Ø 1/2"x2,77 / 450 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 100x40x4 mm / 1.300 mm, 25x15x2 mm / 450 mm
Form tube square (section / min. diameter): 80x80x5 mm / 1.500 mm, 25x25x2 mm / 450 mm
Angle leg outside (Querschnitt / min. Durchmesser): 100x100x12 mm / 1.000 mm, 40x40x4 mm / 700 mm
Angle leg inside (section / min. diameter): 100x100x10 mm / 1.000 mm, 40x40x4 mm / 550 mm
UPN leg outside (section / min. diameter): UPN 180 / 900 mm, UPN 30 / 400 mm
UPN leg inside (section / min. diameter): UPN 180 / 1.000 mm, UPN 30 / 400 mm
IPN horizontal position (section / min. diameter): IPN 180 / 1.000 mm, IPN 80 / 400 mm
Length: 1465 mm
Width: 2000 mm
Height: 1700 mm
Weight: 4000 kg

Shaft diameter: 80
Rolls diameter: 260 mm
Driven rolls: 3
Motor power: 7.5 kW
Speed: 6 m/min
Flat steel vertical position (section / min. diameter): 80x15 mm / 800 mm, 40x10 mm / 400 mm
Flat steel horizontal position (section / min. diameter): 125x25 mm / 600 mm, 60x8 mm / 400 mm
Square bar (section / min. diameter): 45x45 mm / 500 mm, 15x15 mm / 350 mm
Round bar (section / min. diameter): Ø 50 mm / 600 mm, Ø 15 mm / 350 mm
Tube (section / min. diameter): Ø 100x2,5 mm / 1.200 mm, Ø 15x1 mm / 350 mm, Ø 3"x5,48 / 800 mm, Ø 3/8"x1,65 / 400 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 80x25x3 mm / 800 mm, 25x15x2 mm / 400 mm
Form tube square (section / min. diameter): 70x70x3 mm / 1.400 mm, 40x40x2 mm / 800 mm
Angle leg outside (Querschnitt / min. Durchmesser): 80x80x8 mm / 800 mm, 40x40x4 mm / 400 mm
Angle leg inside (section / min. diameter): 80x80x8 mm / 1.000 mm, 40x40x4 mm / 400 mm
UPN leg outside (section / min. diameter): UPN 120 / 800 mm
UPN leg inside (section / min. diameter): UPN 120 / 800 mm
IPN horizontal position (section / min. diameter): IPN 120 / 800 mm
Length: 1150 mm
Width: 1200 mm
Height: 1300 mm
Weight: 1600 kg

Shaft diameter: 80
Rolls diameter: 245 mm
Driven rolls: 3
Motor power: 4 kW
Speed: 6 m/min
Flat steel vertical position (section / min. diameter): 100x20 mm / 2000 mm, 80x20 mm / 800 mm, 30x10 / 300
Flat steel horizontal position (section / min. diameter): 125x25 mm / 600 mm, 60x5 mm / 300 mm
Square bar (section / min. diameter): 45x45 mm / 500 mm, 15x15 mm / 380 mm
Round bar (section / min. diameter): Ø 50 mm / 500 mm, Ø 15 mm / 380 mm
Tube (section / min. diameter): Ø 100x2,5 mm / 1.200 mm, Ø 15x1 mm / 380 mm, Ø 3"x5,48 / 800 mm, Ø 1/2"x2,77 / 380 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 80x25x3 mm / 800 mm, 25x15x2 mm / 350 mm
Form tube square (section / min. diameter): 70x70x3 mm / 1.300 mm, 25x25x2 mm / 350 mm
Angle leg outside (Querschnitt / min. Durchmesser): 80x80x8 mm / 800 mm, 30x30x3 mm / 400 mm
Angle leg inside (section / min. diameter): 70x70x7 mm / 700 mm, 30x30x3 mm / 450 mm
UPN leg outside (section / min. diameter): UPN 140 / 1600 mm, UPN 120 / 900 mm, UPN 100 / 800 mm
UPN leg inside (section / min. diameter): UPN 140 / 1.600 mm, UPN 120 / 1000 mm, UPN 100 / 800 mm
IPN horizontal position (section / min. diameter): IPN 120 / 600 mm, IPN 80 / 400 mm
Length: 1450 mm
Width: 1000 mm
Height: 1400 mm
Weight: 1700 kg

Shaft diameter: 60
Upper roll diameter: 215 mm
Lower roll diameter: 215 mm
Driven rolls: 3
Motor power: 1.5 kW
Speed: 4 m/min
Flat steel vertical position (section / min. diameter): 80x20 mm / 1200 mm, 40x10 mm / 400 mm
Flat steel horizontal position (section / min. diameter): 120x25 mm / 600 mm, 50 x 10 mm / 400 mm
Square bar (section / min. diameter): 50x50 mm / 800 mm, 20x20 mm / 400 mm
Round bar (section / min. diameter): Ø 50 mm / 800 mm, Ø 20 mm / 400 mm
Tube (section / min. diameter): Ø 100x2 mm / 1600 mm, Ø 60x2 mm / 500 mm, 3"x3,2 mm / 1600 mm, 1"x2,6 mm / 500 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 80x40x3 mm / 1400 mm, 40x20x2 mm / 500 mm
Form tube square (section / min. diameter): 70x3 mm / 1600 mm, 40x2 mm / 500 mm
Angle leg outside (Querschnitt / min. Durchmesser): 70x70x7 mm / 1000 mm, 40x40x5 mm / 500 mm
Angle leg inside (section / min. diameter): 70x70x7 mm / 1200 mm, 40x40x5 mm / 600 mm
Length: 1000 mm
Width: 1400 mm
Height: 1650 mm
Weight: 950 kg

Max. sheet thickness - mild steel: 8 mm
Max. thickness - stainless steel: 5 mm
Max. flanging radius: 80 mm
Min. flanging radius: 10
Max. blank diameter: 4500 mm
Min. blank diameter: 720 mm
Max. flanging height: 150 (R 100) / 190 (R 25) mm
rotating speed: 0,35 - 0,68 m/sek.
Motor: 11 kW
Length: 4900 mm
Width: 1700 mm
Height: 2700 mm
Weight: 4550 kg

X-axis: 1000 mm
Y-axis: 400 mm
Positioning speed: 12 m/min
Weight: 300 kg
