pressing capacity: 320 to
Bending length: 4050 mm
Axes: Y1 / Y2 / X
Stroke: 365 mm
Inside distance between side frames: 3600 mm
Gap in side frame: 450 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 160 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 140
Back gauge speed X-axis: 500
Back gauge speed R-axis: 350 mm/s
Back gauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 154 mm
Oiltank: 250 l
Motor power: 18.5 kW
Length: 5250 mm
Width: 1770 mm
Height: 2850 mm
Weight: 20000 kg

pressing capacity: 600 to
Bending length: 6050 mm
Axes: Y1 / Y2 / X und R Achse
Stroke: 365 mm
Inside distance between side frames: 5100 mm
Gap in side frame: 510 mm
Daylight: 700 mm
Power concept: hydraulic
rapid speed Y-axis: 80 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 80
Back gauge travel X-axis: 750 mm
Oiltank: 280 l
Motor power: 2 x 11 kW
Length: 7600 mm
Width: 2650 mm
Height: 3950 mm
Weight: 52500 kg

pressing capacity: 400 to
Bending length: 6050 mm
Axes: Y1 / Y2 / X und R Achse
Stroke: 365 mm
Inside distance between side frames: 5100 mm
Gap in side frame: 510 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 150 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 150
Back gauge travel X-axis: 750 mm
Oiltank: 160 l
Motor power: 2x11 kW
Length: 7500 mm
Width: 2110 mm
Height: 3810 mm
Weight: 34600 kg

pressing capacity: 320 to
Bending length: 6050 mm
Axes: Y1 / Y2 / X und R Achse
Stroke: 365 mm
Inside distance between side frames: 5100 mm
Gap in side frame: 450 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 160 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 160
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge travel R-axis: 250 mm
Table height: 1100 mm
Table width: 154 mm
Oiltank: 160 l
Motor power: 2 x 11 kW
Length: 7500 mm
Width: 1910 mm
Height: 3350 mm
Weight: 29000 kg

pressing capacity: 400 to
Bending length: 4050 mm
Axes: Y1 / Y2 / X und R Achse
Stroke: 365 mm
Inside distance between side frames: 3400 mm
Gap in side frame: 410 mm
Daylight: 630 mm
Power concept: hydraulic
rapid speed Y-axis: 160 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 160
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 154 mm
Motor power: 2 x 11 kW
Length: 5750 mm
Width: 2110 mm
Height: 3450 mm
Weight: 27780 kg

Working area: 4000 x 2000 mm
Table height: 850 mm
load capacity: 8000 kg
height of side panels: 200 mm
Boring Ø: 28 mm
Weight: 712 kg

pressing capacity: 60 to
Bending length: 2050 mm
Axes: 4 (Y1, Y2, X, R)
Stroke: 265 mm
Inside distance between side frames: 1700 mm
Gap in side frame: 450 mm
Daylight: 530 mm
Power concept: hydraulic
rapid speed Y-axis: 200 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 110
Back gauge travel X-axis: 650 mm
Back gauge speed X-axis: 500
Back gauge speed R-axis: 350 mm/s
Back gauge travel R-axis: 250 mm
Table height: 900 mm
Table width: 104 mm
Oiltank: 100 l
Motor: 7.5 kW
Back gauge: 650 mm
Length: 3200 mm
Width: 1550 mm
Height: 2850 mm
Weight: 5600 kg

Working area: 2000 x 1000 mm
Table height: 850 mm
Boring Ø: 28 mm
Weight: 450 kg

Working area: 2000 x 1000 mm
Table height: 850 mm
load capacity: 8000 kg
Boring Ø: 28 mm
Weight: 712 kg

Bending length: 2040 mm
Sheet thickness (420 N/mm²): 0.8 mm
Max. bending angle: 70 °
Length: 2400 mm
Width: 750 mm
Height: 850 mm
Weight: 290 kg

Revs: 40 – 1.300 r.p.m.
Taper: ISO 30
Working area: 465 x 230 x 380 mm
Table: 1000 x 280 mm
Motor: 2.2 kW
Spindle head tiltable left-right: 90 °
Spindle speed (load-free): 115 – 1.750 (115, 230,290,360,580,720,875,1.750) rpm
Length: 1400 mm
Width: 1300 mm
Height: 2200 mm
Weight: 1120 kg

Max. thickness - mild steel: 5 mm
Throat depth: 1200 mm
Motor: 2,2+0,75 kW
Speed: 4 m/min
min / max diameter: 250 / 2000 mm
gap on blade side: 300 mm
Length: 3000 mm
Width: 750 mm
Height: 1400 mm
Weight: 1350 kg

Blade length: 197 mm
Sheet thickness (420 N/mm²): 4 mm
Sheet thickness (600 N/mm²): 2 mm
Strokes: 20 1/min
Angle: 90 °
Motor: 4 kW
Length: 890 mm
Width: 780 mm
Height: 1115 mm
Weight: 550 kg

Working width: 1350
Sheet thickness range - mild steel: 0,4 - 120 mm
Grinding belt dimensions: 1370 x 2200 mm
Suction capacity: 6000 m³/h
Connection for dust collector diam.: 150 mm
Air connection: 6 bar
Length: 4200 mm
Width: 2300 mm
Height: 2350 mm
Weight: 4200 kg

Max. sheet thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Max. flanging radius: 70 mm
Max. blank diameter: 4000 mm
Min. blank diameter: 550 mm
Motor: 8.75 kW
Length: 4250 mm
Width: 720 mm
Height: 2000 mm
Weight: 2015 kg

pressing capacity: 135 to
Bending length: 3050 mm
Axes: 4
Stroke: 320 mm
Inside distance between side frames: 3340 mm
Daylight: 500 mm
Power concept: servomotorized belt drive
rapid speed Y-axis: 100 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 100
Back gauge travel X-axis: 650 mm
Back gauge travel R-axis: 250 mm
Length: 4200 mm
Width: 2200 mm
Height: 2550 mm
Weight: 7300 kg

Drilling capacy mild steel: 40 mm
Spindle cone: MK 4
Distance spindle - column: 300 mm
Revs: 75 - 150 - 235 - 325 - 470 - 650 - 1.050 - 2.100 r.p.m.
Motor: 1.3 kW
Tapping capacity: Stahl: M 30, Guss: M 32
Feeds: 0,1 — 0,2 — 0,3 mm/r
max. drilling depth: 160 mm
Column diameter: 125 mm
Table: 420 x 400 mm
Length: 600 mm
Width: 640 mm
Height: 2020 mm
Weight: 305 kg

pressing capacity: 80 to
Bending length: 2550 mm
Axes: 4
Stroke: 320 mm
Inside distance between side frames: 2840 mm
Daylight: 500 mm
Power concept: servomotorized belt drive
rapid speed Y-axis: 105 mm/s
Working speed Y-axis: 10
Retractionspeed Y-axis: 105
Back gauge travel X-axis: 650 mm
Back gauge travel R-axis: 250 mm
Length: 3700 mm
Width: 2200 mm
Height: 2550 mm
Weight: 6400 kg

Drilling capacy mild steel: 40 mm
Spindle cone: MK 4
Distance spindle - column: 300 mm
Revs: variabel 80 - 1.170 U/min r.p.m.
Motor: 2.4 kW
Tapping capacity: M32
Feeds: automatisch 0,10 - 0,20 (2) mm/r
Column diameter: 125 mm
Distance spindle - table: 150 - 950 mm
Distance spindle-base: 1.31 mm
Table: 400 x 420 mm
Quill travel: 190 mm
Length: 655 mm
Width: 440 mm
Height: 1960 mm
Weight: 295 kg

pressing capacity: 120 to
Bending length: 3100 mm
Stroke: 160 mm
Inside distance between side frames: 2550 mm
Gap in side frame: 240 mm
rapid speed Y-axis: 100 mm/s
Working speed Y-axis: 10
Table width: 230 mm
Motor: 11 kW
Back gauge: 600 mm
Retraction speed: 77 mm/s
Length: 3300 mm
Width: 2150 mm
Height: 2600 mm
Weight: 7500 kg

Grinding width: 150 mm
Grinding belt dimensions: 2.000 x 150 mm
Contact wheel: 200 x 150 x 42ø mm
Straight grinding area: 605 mm
Revs: 1400 - 2800 1/min
Motor: 3/5,9 kW
Length: 1025 mm
Width: 600 mm
Height: 1000 mm
Weight: 100 kg

Grinding width: 75 mm
Grinding belt dimensions: 2.000 x 75 mm
Contact wheel: 200 x 75 x 42 ø mm
Straight grinding area: 605 mm
Revs: 1400 - 2800 1/min
Motor: 3 / 3,5 kW
Length: 1025 mm
Width: 500 mm
Height: 1000 mm
Weight: 76 kg

pressing capacity: 30 to
Stroke: 200 mm
Ram: 500х800 mm
Table: 500х800 mm
Daylight: 450 mm
Rapid speed: 100 mm/s
Working speed: 18 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Length: 1950 mm
Width: 1750 mm
Height: 2650 mm
Weight: 4700 kg

Bending length: 1020 mm
Sheet thickness (420 N/mm²): 1.25 mm
Max. bending angle: 135 °
Stroke of upper flange: 50 mm
Length: 1500 mm
Width: 700 mm
Height: 1250 mm
Weight: 200 kg

pressing capacity: 100 to
Stroke: 500 mm
Ram: 600 x 900 mm
Table: 700 x 1100 mm
Daylight: 750 mm
Throat depth: 320 mm
Rapid speed: 100 mm/s
Working speed: 8 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Working pressure: 240 bar
Die cushion pressing force: 30 to
Die cushion stroke: 200 mm
Table Drill Ø: 120 mm
Draw cushion working pressure: 170 bar
Draw cushion retraction speed: 52 mm/sec.
Draw cushion surface: 700 x 400 mm

pressing capacity: 150 to
Stroke: 500 mm
Ram: 950 x 650 mm
Table: 1200 x 750 mm
Daylight: 750 mm
Rapid speed: 100 mm/s
Working speed: 5 mm/s
Retraction speed: 165 mm/s
Motor: 11 kW
Working pressure: 254 bar
Die cushion pressing force: 32 to
Die cushion stroke: 200 mm
Table Drill Ø: 120 mm
Draw cushion working pressure: 160 bar
Draw cushion retraction speed: 40 mm/sec.
Length: 2225 mm
Width: 1600 mm
Height: 3850 mm
Weight: 10000 kg

6V Openings: 86° 10/15/20/30/40/50mm planed mm
Length: 3100 mm
Width: 80 mm
Height: 80 mm

Height: 190 mm

6V Openings: 10/20/30/50/80/120mm mm
Length: 7000 mm
Width: 160 mm
Height: 160 mm

Laser power: 4 kW
Manual table / shuttle table: Manual table
Max. thickness - mild steel: 20 mm
Max. thickness - stainless steel: 10 mm
Max. thickness - aluminium: 12 mm
Max. Application Range - Copper: 6 mm
Max. Application Range - Brass: 10 mm
Cutting area: 3.048 x 1.530 mm
X-axis: 3048 mm
Y-axis: 1530 mm
Z-Axis: 125 mm
Max. Sheet size: 3.048 x 1.524 mm
Max. sheet weight: 127 kg/m²
Max speed x-axes: 90 m/min
Max speed y-axes: 90 m/min
Max. speed simultaneous: 127 m/min
Max. acceleration: 14 m/s²
Positioning accuracy: +/- 0,05 mm
Repeat accuracy: +/- 0,05 mm
Total space length U: 5310 mm
Total space width G: 2810 mm
Height: 1860 mm
Weight: 6600 kg

Cutting length: 3100 mm
Max. thickness - mild steel: 6 mm
Max. thickness - stainless steel: 4 mm
Gap in side frame: 50 mm
Strokes: 15 1/min
Cutting angle: 1 °
Number of downholders: 16 pcs.
Pressure of downholder: 14 to
Back gauge: 1000 mm
Back gauge speed: 200 mm/s
Motor power: 15 kW
Oiltank: 200 l
Support arms: 2 pcs.
Table height: 865 mm
Table width: 500 mm
Table length: 3515 mm
Length: 4110 mm
Width: 2200 mm
Total width with support arm und protection fence: 3700 mm
Height: 2100 mm
Weight: 7300 kg

Grinding belt dimensions: 100 x 2.000 mm
Tube diameter: 20 - 76,1
Hand lever adjustment: 1
Handwheel adjustment: 1
Motor power: 3 kW
Weight: 220 kg

Shaft diameter: 60
Rolls diameter: 177 mm
Driven rolls: 3
Motor power: 3.7 kW
Speed: 6 m/min
Flat steel vertical position (section / min. diameter): 70x10 mm / 600 mm, 30x10 mm / 250 mm
Flat steel horizontal position (section / min. diameter): 90x25 mm / 500 mm, 50x5 mm / 250 mm
Square bar (section / min. diameter): 40x40 mm / 500 mm, 20x20 mm / 300 mm
Round bar (section / min. diameter): Ø. 40 mm / 500 mm, Ø 20 mm / 300 mm
Tube (section / min. diameter): Ø 60x2 mm / 600 mm, Ø 20x1 / 250 mm
Form tube vertical position (Querschnitt / min. Durchmesser): 80x40x3 mm
Form tube square (section / min. diameter): 60x60x4 mm
Angle leg outside (Querschnitt / min. Durchmesser): 50x5 mm / 1.000 mm, 30x4 mm / 350 mm
Angle leg inside (section / min. diameter): 50x5 mm / 500 mm, 30x3 mm / 250 mm
Length: 1160 mm
Width: 1000 mm
Height: 1175 mm
Weight: 1194 kg

Working width: 1350
Sheet thickness range - mild steel: 0,6 - 170 mm
Grinding belt dimensions: 1120 x 2200 mm
Suction capacity: 4000 m³/h
Connection for dust collector diam.: 200 mm
Air connection: 6 bar
Noise level: 78 (+/-2) dB
Length: 1750 mm
Width: 2100 mm
Height: 2180 mm
Weight: 2000 kg

Length: 835 mm

Jaw opening: 200 mm
jaw height: 63 mm
Opening of upper beam: 160 mm

Jaw opening: 200 mm
jaw height: 62 mm
Opening of upper beam: 300 mm
Clamping Force: 8500 kg
Weight: 110 kg

Revs: 63 - 3150 (18) r.p.m.
Working area: 700 x 500 x 500 mm
Table: 900 x 500 mm
Motor: 6.6 kW
Maximal table load: 500 kg
Quill travel: 100 mm
Length: 2150 mm
Width: 2220 mm
Height: 2120 mm
Weight: 2550 kg

Cutting area: 4000x2000 mm
Nominal power: 37 kW
Max. material thickness: bei Wasserstrahl
Steel: 200 mm
Stainless Steel: 150 mm
Aluminium: 120 mm
Glass: 100 mm
PVC: 150 mm
Number of cutting heads: 1
Effective cutting range x axis: 4000 mm
Effective cutting range y axis: 2000 mm
Z axis travel: 200 mm
Max. simultaneous positioning speed: 60 m/min
Max. cutting speed: 20 m/min
Machine tolerance according to VDI/DGQ 3441: +/- 0,05 mm/m
Repeatability precision: +/- 0,025 mm/m
Tank volume: 6 m3
Maximum supported weight for the workpiece: 790 kg/m2
High pressure pump nominal power: 37 kW / 50 PS
High pressure pumpb maximum working pressure: 4136 bar
Maximum flow: 4 l/min

pressing capacity: 120 to
Bending length: 3050 mm
Axes: 4 (Y1, Y2, X, R)
Stroke: 180 mm
Inside distance between side frames: 2550 mm
Gap in side frame: 250 mm
Daylight: 375 mm
Power concept: hydraulic
Back gauge travel X-axis: 620 (with optional R-axis: 500 mm) mm
Table height: 878 mm
Table width: 104 mm
Oiltank: 150 l
Motor power: 11 kW
Length: 3750 mm
Width: 1230 mm
Height: 2400 mm
Weight: 5900 kg

Drilling capacy mild steel: 42 mm
Spindle cone: MK 4
Distance spindle - column: 280 – 1100 mm
Revs: 44 – 1.500 (12) r.p.m.
Tapping capacity: M 25 / M 28
Distance table - spindle underside: 470 – 1.270 mm
automatic feed: 0,05 – 0,15 (3) mm/min
Spindle motor: 2.2 kW
Quill travel: 280 mm
Table: 1725 x 715 x 180 mm
Box table dimensions: 635 x 520 x 415 mm
max. height: 2530 mm
Length: 1880 mm
Width: 870 mm
Height: 2210 mm
Weight: 2600 kg

Length: 1500 mm
Weight: 3 kg
Width: 200 mm

Weight: 2 kg
Width: 200 mm
Height: 130 mm

Working height: 820 - 940 mm
Maximal table load: 900 kg
Max. load per meter: 300 kg/m
width of rolls: 350 mm
diameter of rolls: 60 x 2 mm
axis diameter: 15 mm
max. gauge length: 2550 mm
roll gapping: 250 mm
Length: 3000 mm

Working height: 820 - 940 mm
Maximal table load: 900 kg
Max. load per meter: 300 kg/m
width of rolls: 350 mm
diameter of rolls: 60 x 2 mm
axis diameter: 15 mm
max. gauge length: 2550 mm
roll gapping: 250 mm
Length: 3000 mm

Working height: 820 - 940 mm
Maximal table load: 900 kg
Max. load per meter: 300 kg/m
width of rolls: 350 mm
diameter of rolls: 60 x 2 mm
axis diameter: 15 mm
max. gauge length: 2550 mm
roll gapping: 250 mm
Length: 3000 mm

Working height: 610 - 920 mm
Maximal table load: 700 kg
width of rolls: 350 mm
diameter of rolls: 52 mm
number of rolls: 1
Weight: 20 kg

Working height: 530 - 870 mm
Maximal table load: 700 kg
width of rolls: 2 x 125 mm
diameter of rolls: 52 mm
number of rolls: 2
Weight: 20 kg

T-slots: 22 mm
Length: 420 mm
Width: 450 mm
Height: 250 mm

Length: 515 mm
Height: 220 mm
